PTO Link Duo Bundle Compact Quick-Connect System with 1 Tractor/Female Plate and 1 Implement/Male Plate for Tractors Up to 70 HP
Item # 227348199
Neighbor’s Club Members earn points with purchases.
PTO Link Duo Bundle Compact Quick-Connect System with 1 Tractor/Female Plate and 1 Implement/Male Plate for Tractors Up to 70 HP
Item # 227348199
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The PTO Link Compact System is designed for ONLY category 1 tractors (compact or subcompact, with a max 70 HP/engine net rating), used in combination with category 1 implements ONLY. PTO Link is the original, universal PTO quick-connect system consisting of two interconnecting steel couplers. Its patented Open-Plate design replaces the traditional spline-to-driveline connection with a visible interface that's both easy to see and reach. Now you can quickly and safely connect / disconnect implements at the tractor's PTO in just seconds! This complete PTO Link System includes both a Tractor (Female) Coupler and an Implement (Male) Coupler. For best results, every tractor should be equipped with a Tractor Coupler, and every implement should be equipped with an Implement Coupler.
- Rear 6-spline 540 RPM PTO for category 1 tractors & category 1 implements ONLY.
- *NOTICE for Kubota BX tractors ONLY! The specially designed PTO Link Compact System - Lift Arm Stabilizer Replacement Plate is an additional requirement for all BX series tractors.
- PTO Link Compact System - Safety Bolt included with every Tractor Coupler Extras can be purchased separately.
- Simple one-step installation and easy removal for each Coupler without special hardware or installation tools.
- Built to last (Modified AISI 4140 hardened alloy steel with QPQSM finish)
- Limited warranty covers all manufacturing defects in materials or workmanship of all PTO Link parts for one year from the date of purchase.
- Tractor Coupler Dimensions: 3.75 W x 4.25 H; Implement Coupler Dimensions: 3.75 W x 4.0625 H
- Tractor Coupler Weight: 3.8 lbs; Shipping weight: 4 lbs; Implement Coupler Weight: 2.7 lbs; Shipping weight: 3 lbs.
- Safety and Operation: The PTO Link System adds approximately 5 inches to the overall length of the implement driveline when fully installed. To avoid any possible damage or injury requires carefully measuring the driveline length for possible adjustments and reviewing all installation instructions and operational specs before operating the PTO Link.
- The PTO Link Compact System is NOT compatible or interchangeable with other PTO Link systems due to the specific design of the connecting components for each system.
- As an essential safety precaution, be sure to turn off the tractors engine during installation, shield any rotating parts, and do not wear any loose clothing that could become entangled and pulled into the machine. PTO safety is critical, and every precaution should be taken.
- The PTO Link system is NOT an adapter. To comply with ASABE standards, do not use PTO Link in combination with PTO adapters.
