Mega 10 hp Upright 35 CFM, 175 PSI, 200 PSI Max, 3 Phase Power 208/230 V Two Stage
Mega 10 hp Upright 35 CFM, 175 PSI, 200 PSI Max, 3 Phase Power 208/230 V Two Stage
Item # 6152250
$5099.99
Add a protection plan
Powersport plans are not available in CA & MD.
Mega 10 hp Upright 35 CFM, 175 PSI, 200 PSI Max, 3 Phase Power 208/230 V Two Stage
Item # 6152250
$5099.99
Add a protection plan
Powersport plans are not available in CA & MD.
The Mega Compressor 120 gallon 10 HP, vertical air compressor (MP-10120V3-U) is ideal for multiple operating air tools and industrial work. This compressor has high air flow of 37 CFM at 90 PSI a maximum 35 CFM @ 175 PSI to power a wide variety of air tools and a 3-Phase Magnetic Starter. The heavy-duty, cast-iron, 2-Stage, 3-cylinder pump is oil lubricated for a long-life. The durable, 120 gallon ASME-certified tank is a vertical design for space saving in the shop or warehouse.
- Cast iron, W cylinder, oil lubricated pump
- Heavy duty induction motor for maximum performance and efficiency
- 120 gallon vertical Tank
- 230V/460V Three Phase Motor
- Shipped with 100% full synthetic air compressor oil for optimum performance and long life
- Build In USA
| Brand | Mega |
|---|---|
| Country of Origin | Made in USA |
| Airflow Volume | 35 CFM |
| Air Outlet Size | 0.75 in. |
| Amperage | 24 A |
| Compressor Horsepower | 10 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 175 PSI |
| Compressor Operation | Automatic start/stop |
| Compressor Tank Capacity | 120 gal |
| Compressor Voltage | 208V/230V |
| Drain System | Manual Drain |
| Drive Type | Belt Drive |
| Features | Heavy-duty induction motor with cast iron W-cylinder oil-lubricated pump, 120-gallon vertical tank, 230/460V 3-phase motor, and full synthetic air compressor oil for long-lasting performance. |
| Phase | Triple |
| Number Of Power Speeds | Single |
| Power Type | Electric |
| Primary Color | Black |
| Primary Material | Cast Iron |
| Product Height | 80 in. |
| Product Length | 35 in. |
| Product Weight | 980 lb. |
| Product Width | 44 in. |
| Pump Material | Cast iron |
| Stage Type | Two-Stage |
| Tank Style | Vertical |
| Warranty | 1 |
| Manufacturer Part Number | MP-10120V3-U |
