Ingersoll Rand 135-175 PSI Pressure Switch for 2-Stage Compressors
$149.99
Ingersoll Rand 135-175 PSI Pressure Switch for 2-Stage Compressors
Ingersoll Rand 135-175 PSI Pressure Switch for 2-Stage Compressors
Item # 1076471
$149.99
Buy Air Compressor Get 20% Off Air Compressor accessorie
Get everything you need
Neighbor’s Club Members earn points with purchases.
Ingersoll Rand 135-175 PSI Pressure Switch for 2-Stage Compressors
Item # 1076471
Buy Air Compressor Get 20% Off Air Compressor accessorie
$149.99
New Cardmembers earn a $75 Reward‡ with qualifying purchase of $75 or more plus earn 5% in Rewards+ on this purchase. Valid through 7/12/26.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
Protect your air compressor investment with this Ingersoll Rand Pressure Switch for 2-Stage Compressor. Using a pressure switch ensures your compressor will shut off once it reaches the pressure level you have indicated. This pressure switch is compatible with the 5 HP 2-stage Ingersoll Rand compressor. The replacement pressure switch measures 4.5 in. L x 4 in. H x 4 in. W.
- Pressure switch for 2-stage compressor has a 1 year limited warranty
- Replacement pressure switch for the 5 HP 2-stage Ingersoll Rand compressor
- Pressure switch ensures your compressor will shut off when it reaches the desired pressure level
- Dimensions of pressure switch: 4.5 in. L x 4 in. H x 4 in. W
- 135 psig cut-in, 175 psig cut-out
- Includes unloader valve
- Includes Shut Off Switch on Side of Pressure Switch
- Extremely important to use Teflon Tape when installing on compressor. Please review video or contact our Air Tech team at 800-247-7378 for assistance
- NEMA 1 type enclosure
| Brand | Ingersoll Rand |
|---|---|
| Country of Origin | Made in USA |
| Inlet Diameter | 0 in. |
| Inlet Type | Compression |
| Maximum On/Off Factory Pressure Setting | 135 psig cut - in. , 175 psig cut -out |
| Maximum Operating Pressure | 135 psig cut - in. , 175 psig cut -out |
| Minimum On/Off Factory Pressure Setting | 135 psig cut - in. , 175 psig cut -out |
| Minimum Operating Pressure | 135 psig cut - in. , 175 psig cut -out |
| On/Off Factory Pressure Setting | 135 psig cut - in. , 175 psig cut -out |
| Operating Pressure Range | 135 psig cut - in. , 175 psig cut -out |
| Outlet Diameter | 0 in. |
| Outlet Type | N/A |
| Primary Material | Plastic |
| Product Height | 5 in. |
| Product Length | 6in. |
| Product Weight | 2 lb. |
| Product Width | 6 in. |
| Warranty | 6 Month |
| Manufacturer Part Number | 23474653-R |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 27 Questions
Newest questions
Q: TS5 replacement switch? There are 2, which one do I need to buy?
7 months ago1 Answer
- A: If you are looking for the replacement pressure switch for the TS4N5 Air Compressor then the replacement pressure switch is TSC SKU# 1076471 this is Ingersoll Rand part number 23474653 please see below link to this on the Tractor Supply Website. https://www.tractorsupply.com/tsc/product/ingersoll-rand-pressure-switch-for-2-stage-compressor-1076471 thank you,7 months agoHelpful?
Q: Do you have this item Ingersol-Rand pressure switch #56288798 or a cross-reference part number?
10 months ago1 Answer
- A: Please reach out directly to our Air Compressor Technical team on this one at 800-247-7378 Part number 56288798 is a old discontinued item and there are replacements but we would need to determine a few more details about your unit because based on the year built there are different kits or switches that go with each. They will be able to provide you with the correct option and get you in touch with where you can purchase what is needed. thank you,9 months agoHelpful?
Q: Will this work for 230 volt compressors?
a year ago1 Answer
- A: This will work with the TSC stocked TS4N5 model, the other stocked TSC unit the 2475N7.5 model uses a different pressure switch. That unit uses this pressure switch https://www.tractorsupply.com/tsc/product/ingersoll-rand-two-stage-pressure-switch-for-2475n75-2545k10-2545e10-23474570 thank you,a year agoHelpful?
Q: Does this switch have a lever as in pic of Single Stage unit or is it preset? Is the preset adjustable by spring tension?
2 years ago1 Answer
- A: This pressure switch has the on / off switch on the side as shown in the picture. If you have adjustment issues or questions please reach out to our technical team who can walk you through any questions 800-247-7378 there are also a couple of videos on the product listing on Tractor Supply's website that talk about the pressure switch. thank you,2 years agoHelpful?
Q: need regulator switch for 80 gallon IR compressor i got from tractor supply
3 years ago1 Answer
- A: Hi there, I would recommend contacting the manufacturer. Ingresoll Rand https://www.ingersollrand.com/en-us/modals/contact3 years agoHelpful?
Q: Can you adjust the pressure on this switch?
3 years ago1 Answer
- A: Hi, You can not, Using this pressure switch ensures your compressor will shut off once it reaches the pressure level you have indicated.3 years agoHelpful?
Q: Is this switch a replacement for 23474653A
4 years ago1 Answer
- A: Hi D D ret, this is a Replacement for SKU# 3496129 (TS4N5) , 2340L5-V , 2340N5-V , 2340D-V its also Compatible with SKU# 3496129 (TS4N5) , 2340L5-V , 2340N5-V , 2340D-V3 years agoHelpful?
Q: How many AMPS is this switch rated for? I know it's 120 volts. Big difference. 15, 20 30 amps?
4 years ago1 Answer
- A: This pressure switch is intended to be used on models 2340L5 / 2340N5 / & TS4N5 which have a 21.5 Full Load amp rating.4 years agoHelpful?
Q: What is the amperage rating for this pressure switch?
4 years ago1 Answer
- A: 120 volts4 years agoHelpful?
Q: Will this work on the 7.5 hp 80 gall if not where can I find it
5 years ago1 Answer
- A: This product is compatible with 5 HP 2-stage Ingersoll Rand compressors.5 years agoHelpful?
1 - 10 of 27 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 27 Questions
Newest questions
Q: TS5 replacement switch? There are 2, which one do I need to buy?
7 months ago1 Answer
- A: If you are looking for the replacement pressure switch for the TS4N5 Air Compressor then the replacement pressure switch is TSC SKU# 1076471 this is Ingersoll Rand part number 23474653 please see below link to this on the Tractor Supply Website. https://www.tractorsupply.com/tsc/product/ingersoll-rand-pressure-switch-for-2-stage-compressor-1076471 thank you,7 months agoHelpful?
Q: Do you have this item Ingersol-Rand pressure switch #56288798 or a cross-reference part number?
10 months ago1 Answer
- A: Please reach out directly to our Air Compressor Technical team on this one at 800-247-7378 Part number 56288798 is a old discontinued item and there are replacements but we would need to determine a few more details about your unit because based on the year built there are different kits or switches that go with each. They will be able to provide you with the correct option and get you in touch with where you can purchase what is needed. thank you,9 months agoHelpful?
Q: Will this work for 230 volt compressors?
a year ago1 Answer
- A: This will work with the TSC stocked TS4N5 model, the other stocked TSC unit the 2475N7.5 model uses a different pressure switch. That unit uses this pressure switch https://www.tractorsupply.com/tsc/product/ingersoll-rand-two-stage-pressure-switch-for-2475n75-2545k10-2545e10-23474570 thank you,a year agoHelpful?
Q: Does this switch have a lever as in pic of Single Stage unit or is it preset? Is the preset adjustable by spring tension?
2 years ago1 Answer
- A: This pressure switch has the on / off switch on the side as shown in the picture. If you have adjustment issues or questions please reach out to our technical team who can walk you through any questions 800-247-7378 there are also a couple of videos on the product listing on Tractor Supply's website that talk about the pressure switch. thank you,2 years agoHelpful?
Q: need regulator switch for 80 gallon IR compressor i got from tractor supply
3 years ago1 Answer
- A: Hi there, I would recommend contacting the manufacturer. Ingresoll Rand https://www.ingersollrand.com/en-us/modals/contact3 years agoHelpful?
Q: Can you adjust the pressure on this switch?
3 years ago1 Answer
- A: Hi, You can not, Using this pressure switch ensures your compressor will shut off once it reaches the pressure level you have indicated.3 years agoHelpful?
Q: Is this switch a replacement for 23474653A
4 years ago1 Answer
- A: Hi D D ret, this is a Replacement for SKU# 3496129 (TS4N5) , 2340L5-V , 2340N5-V , 2340D-V its also Compatible with SKU# 3496129 (TS4N5) , 2340L5-V , 2340N5-V , 2340D-V3 years agoHelpful?
Q: How many AMPS is this switch rated for? I know it's 120 volts. Big difference. 15, 20 30 amps?
4 years ago1 Answer
- A: This pressure switch is intended to be used on models 2340L5 / 2340N5 / & TS4N5 which have a 21.5 Full Load amp rating.4 years agoHelpful?
Q: What is the amperage rating for this pressure switch?
4 years ago1 Answer
- A: 120 volts4 years agoHelpful?
Q: Will this work on the 7.5 hp 80 gall if not where can I find it
5 years ago1 Answer
- A: This product is compatible with 5 HP 2-stage Ingersoll Rand compressors.5 years agoHelpful?
1 - 10 of 27 Questions
Similar Items
-
-
-
-
-
-
Top Rated
-
-
-
-
-
-
Top Rated
Items You May Like
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Top Rated
Reviews
Summary of Reviews
The product has mixed reviews regarding its quality and reliability. Some users report the switch working well and being easy to replace, while others experienced issues with the switch not functionin...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
4 out of 5 stars.
Replaced original part early
6 years ago
The pressure switch installed easily. My concerns are why did the pressure switch fail. Purchased compressor from TSC under 3 yrs ago. Limited usage only airing up tires and air tools 15-20 times a year max. New tags still hanging on compressor from purchase! Had 2 year warranty.
6 people found this helpful
Show Reviews:
Most Helpful Critical Review
1 out of 5 stars.
Not again
6 years ago
We bought a 2 stage Ingersoll rand air compressor for our body shop 2 years ago, have replaced the pressure switch twice and the motor once, tired to contact Ingersoll rand, they would not return our calls.
6 people found this helpful
Show Reviews:
- purchase
- quality
- installation
- adjustability
- oem
- price
- satisfaction
- secure
1 to 4 of 145 Reviews .
1 – 4 of 145 Reviews
Most Recent
Franklin, IN
Review 1
5 out of 5 stars.
Exact part to get my shop back up and running!
4 months ago
Wasn’t in stock, so received in store help to order and then delivered to my home.
SweepstakesYes
Yes, I recommend this product.
TUCSON,AZ
Review 1
5 out of 5 stars.
IR REPLACEMENT SAME FOR SAME
4 months ago
SAME AS THE ONE I REPLACED
Ottawa, Ks
Review 1
5 out of 5 stars.
Review for Ingersoll Rand 135-175PSI Press. Switch
6 months ago
Pressure worked as it should. Easy to swap out, and our compressor was back to working.
I was lucky that Tractor Supply had it in stock for store pickup and that I didn't have to wait to ship from elsewhere online. They saved us time having it available.
Yes, I recommend this product.
Reviews 3
5 out of 5 stars.
Replacement parts for air compressor.
7 months ago
Worked great for my repair
