Ingersoll Rand 5 hp 60 gal. 2-Stage Air Compressor, 175 PSI, 230V, 3-Phase

Shop all Ingersoll Rand

Item # 107274299

$2,239.99

Add a protection plan

What's included

Powersport plans are not available in CA & MD.

Neighbor’s Club Members earn points with purchases.

Shop all Ingersoll Rand

Ingersoll Rand 5 hp 60 gal. 2-Stage Air Compressor, 175 PSI, 230V, 3-Phase

Item # 107274299

$2,239.99

$67/mo.^† for 36 months totaling $2412 at 3.99% APR or earn $111 in Rewards⁺ on this purchase.

This item is available online only

Delivery to

For delivery, this item requires a Big & Bulky handling fee.Learn more

Add a protection plan

What's included

Powersport plans are not available in CA & MD.

Neighbor’s Club Members earn points with purchases.

Power air tools with the Ingersoll Rand 2340L5-V 230V-3Ph 2-Stage Air Compressor. This air compressor is designed for use in commercial, automotive and light industrial applications. The pump in the 2-stage air compressor is made from cast-iron for durability and is oil-lubricated. The air compressor has an automatic stop control with a NEMA 1 pressure switch for safe use.

For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.

Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.

1 year limited warranty/2 year limited pump warranty with use of IR synthetic lubricant
ASME coated 60 gal. vertical tank in the air compressor
14.7 CFM @ 175 PSI
Oil-lubricated cast-iron pump in the air compressor is designed for heavy-duty applications
Designed to run at high volumes and high pressure without interruption
For use with commercial, automotive and light industrial applications with intermittent load demands
ODP electric motor powers the 2-stage air compressor
Automatic stop control on the 2-stage air compressor with a NEMA 1 pressure switch
You can also purchase the 2 Year Warranty Startup Kit for this model which is TSC SKU# 2445775

Brand	Ingersoll Rand
Country of Origin	Made in USA
Airflow Volume	14 CFM
Air Outlet Size	1/2 in.
Amperage	15.2 Amp
Compressor Horsepower	5 HP
Lubrication Type	Oil
Compressor Maximum PSI	175 PSI
Compressor Tank Capacity	60 gal
Compressor Voltage	230V
Drain System	Manual
Drive Type	Reciprocating
Features	Magnetic Starter
Phase	Triple
Number Of Power Speeds	Single
Number Of Wheels	0
Power Type	Electric
Primary Color	Brown
Primary Material	Cast Iron
Product Height	69 in.
Product Length	34 in.
Product Weight	435 lb.
Product Width	20 in.
Pump Material	Cast iron
Tank Style	Vertical
Warranty	1 Year
Manufacturer Part Number	45464955

Q&As

1 - 1 of 1 Question

Q: what is the db. level?

3 years ago

1 Answer

A: Hi, please reach out directly to **INGERSOLL RAND** https://www.ingersollrand.com/en-us/air-compressor/modals/contact Chat on their website or call Phone: (800) 956-0333 8:00 a.m. and 5:00 p.m. Pacific Standard Time, Monday through Friday (except for holidays)
3 years ago
Helpful?

Items You May Like

Reviews

Rating Snapshot

Select a row below to filter reviews.

1 review with 5 stars.

2 reviews with 4 stars.

0 reviews with 3 stars.

1 review with 2 stars.

1 review with 1 star.

Overall Rating

3.2

2 out of 2 (100%) reviewers recommend this product

Review this Product

Select to rate the item with 1 star. This action will open submission form.

Select to rate the item with 2 stars. This action will open submission form.

Select to rate the item with 3 stars. This action will open submission form.

Select to rate the item with 4 stars. This action will open submission form.

Select to rate the item with 5 stars. This action will open submission form.

Adding a review will require a valid email for verification

application
compatibility
metal
purchase
quality
warranty

1 to 3 of 5 Reviews .

1 – 3 of 5 Reviews

Review 1

1 out of 5 stars.

Poor quality worse service

2 years ago

Lasted just past manufacture warranty bought the additional warranty at time of purchase they won’t do anything to help so I have a pile of scrap metal

Weatherford Tx

Reviews 2

4 out of 5 stars.

Does have small leak

3 years ago

I would have given it a 5 star but it leaks down overnight. I can hear a leak bye the switch but can’t find it. I’ve tightened what I was able to reach but did not want to over torque anything. Ball valve was shut off so I’m not sure why it’s leaking in that area unless it’s a bad relief valve ?

Sweepstakes EntryYes

Yes, I recommend this product.

Phila, PA

Review 1

4 out of 5 stars.

HOT AIR

6 years ago

Have not installed yet, need a refridgerated dryer and particulate filters for my application, This model does not have an aftercooler so checked with Ingersoll Rand for the correct dryer to use with this unit - very helpful!

Yes, I recommend this product.
