Ingersoll Rand 5 hp 60 gal. 2-Stage Air Compressor, 175 PSI, 460V, 3-Phase
Ingersoll Rand 5 hp 60 gal. 2-Stage Air Compressor, 175 PSI, 460V, 3-Phase
Item # 107274399
$2,239.99
or
or
Buy Air Compressor Get 20% Off Air Compressor accessorie
Neighbor’s Club Members earn points with purchases.
Ingersoll Rand 5 hp 60 gal. 2-Stage Air Compressor, 175 PSI, 460V, 3-Phase
Item # 107274399
Buy Air Compressor Get 20% Off Air Compressor accessorie
$2,239.99
or
or
$67/mo.† for 36 months totaling $2412 at 3.99% APR or earn $111 in Rewards+ on this purchase.
This item is available online only
Delivery to
For delivery, this item requires a Big & Bulky handling fee.Learn more
Neighbor’s Club Members earn points with purchases.
Power air tools with the Ingersoll Rand 2340L5-V 460V-3Ph 2-Stage Air Compressor. This air compressor is designed for use in commercial, automotive and light industrial applications. The pump in the 2-stage air compressor is made from cast-iron for durability and is oil-lubricated. The air compressor has an automatic stop control with a NEMA 1 pressure switch for safe use.1 Year
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- 1 year limited warranty/2 year limited pump warranty with use of IR synthetic lubricant
- ASME coated 60 gal. vertical tank in the air compressor
- 14 CFM @ 175 PSI
- Oil-lubricated cast-iron pump in the air compressor is designed for heavy-duty applications
- Designed to run at high volumes and high pressure without interruption
- For use with commercial, automotive and light industrial applications with intermittent load demands
- ODP electric motor powers the 2-stage air compressor
- Automatic stop control on the 2-stage air compressor with a NEMA 1 pressure switch
- Designed for heavy shop or industrial use, Ingersoll Rand electric-driven, two-stage air compressors provide the reliability and performance that are ideal for most applications including automotive service and body shops, fleet maintenance, machine shops, production and manufacturing lines, wood working shops, dry cleaners, car washes, general maintenance/repair shops and farms.
- You can also purchase the 2 Year Warranty Startup Kit for this model which is TSC SKU# 2445775
| Brand | Ingersoll Rand |
|---|---|
| Country of Origin | Made in USA |
| Airflow Volume | 14 CFM |
| Air Outlet Size | 1/2 in. |
| Amperage | 7.6 Amp |
| Compressor Horsepower | 5 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 175 PSI |
| Compressor Tank Capacity | 60 gal |
| Compressor Voltage | 460V |
| Drain System | Manual |
| Drive Type | Electric |
| Features | Magnetic Starter |
| Phase | Triple |
| Number Of Power Speeds | Single |
| Number Of Wheels | 0 |
| Power Type | Electric |
| Primary Color | Brown |
| Primary Material | Cast Iron |
| Product Height | 76 in. |
| Product Length | 50 in. |
| Product Weight | 440 lb. |
| Product Width | 50 in. |
| Pump Material | Cast iron |
| Tank Fill Time | 0 minutes |
| Tank Style | Vertical |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | 45464963 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 4 of 4 Questions
Newest questions
Q: Hi I want to be able to run at least 2 DA’s and spray a complete car paint job would this be able to hold up with everything?
4 years ago1 Answer
- A: The 2340L5-V provides 14 cfm at 175 PSI with a max PSI of 175. You would need to determine the CFM requirements for the DA’s to determine if this compressor can handle the requirements. If you have any further questions you can reach out directly to the manufacture's technical team at 800-247-73784 years agoHelpful?
Q: can this run 208 3 phase
6 years ago1 Answer
- A: No, this is a 460 volt motor.6 years agoHelpful?
Q: Can this be run on 230v 3ph?
6 years ago1 Answer
- A: The motor can be rewired to 230/3/60 but the mag starter will need to be changed out to p/n 23859705.6 years agoHelpful?
Q: Can you run this compressor off a generator
7 years ago1 Answer
- A: It is not really recommended to operate compressors off of generators due to the inability of the start up current to be covered by a large enough generator. However, here are the specs required to cover start up of this compressor. Full load amps x voltage x 7 (start up or inrush current) = Kilowatt size of generator 7.6 FLA x 460 volts x 7 = 24472 KW generator.7 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 4 of 4 Questions
Newest questions
Q: Hi I want to be able to run at least 2 DA’s and spray a complete car paint job would this be able to hold up with everything?
4 years ago1 Answer
- A: The 2340L5-V provides 14 cfm at 175 PSI with a max PSI of 175. You would need to determine the CFM requirements for the DA’s to determine if this compressor can handle the requirements. If you have any further questions you can reach out directly to the manufacture's technical team at 800-247-73784 years agoHelpful?
Q: can this run 208 3 phase
6 years ago1 Answer
- A: No, this is a 460 volt motor.6 years agoHelpful?
Q: Can this be run on 230v 3ph?
6 years ago1 Answer
- A: The motor can be rewired to 230/3/60 but the mag starter will need to be changed out to p/n 23859705.6 years agoHelpful?
Q: Can you run this compressor off a generator
7 years ago1 Answer
- A: It is not really recommended to operate compressors off of generators due to the inability of the start up current to be covered by a large enough generator. However, here are the specs required to cover start up of this compressor. Full load amps x voltage x 7 (start up or inrush current) = Kilowatt size of generator 7.6 FLA x 460 volts x 7 = 24472 KW generator.7 years agoHelpful?
