Fimco 12V High-Flo High-Performance Bypass Pump, 2.4 GPM
$129.99
Fimco 12V High-Flo High-Performance Bypass Pump, 2.4 GPM
Fimco 12V High-Flo High-Performance Bypass Pump, 2.4 GPM
Item # 135042599
$129.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
$129.99
New Cardmembers earn a $75 Reward‡ with qualifying purchase of $75 or more plus earn 5% in Rewards+ on this purchase. Valid through 7/12/26.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Fimco 2.4 GPM 12V High-Flo High-Performance Bypass Pump sets the standard for electric pumps. The quick-connect convenience paired with premium parts makes this innovative sprayer replacement pump a great choice for your spot spraying or broadcast spraying needs. With 60 PSI maximum pressure, this Fimco bypass pump delivers increased flow rates and a longer lifespan.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 2.4 GPM electric sprayer bypass pump for spot spraying or broadcast spraying needs
- 12VDC power sprayer pump is equipped with a ball-bearing drive
- Bypass pump will run continuously without damage once pressure is reached or unless shut off
- In-line fuse protection - 8A max draw
- 3/8-in. FNPT inlet and outlet ports
- Self priming up to 14 ft.
- Runs dry without damage
- Fimco bypass pump is 100% factory tested for quality assurance
- Maximum pressure of 60 PSI
- Chemically resistant elastomers provide increased flow rate delivering superior performance
- Replaces pump part numbers 5281373, 5275814, 5277995 and 5275651
- Internally fan-cooled motor delivers consistent performance under heavy load
- Backed by a 2-year (consumer) and 90-day (commercial use) warranty
- Max operating temperature: 130 degrees F
| Brand | Fimco |
|---|---|
| Country of Origin | Imported |
| Compatibility | Fimco, TSC Sprayers |
| Inlet Connection | Threaded Female |
| Maximum Flow Rate | 2.4 GPM |
| Maximum Operating Pressure | 60 PSI |
| Maximum Operating Temperature | 130 degrees F |
| OEM Replacement | 5281373, 5275814, 5277995 and 5275651 |
| Package Quantity | 1 |
| Primary Color | Red |
| Primary Material | Steel |
| Product Height | 3-1/4 in. |
| Product Length | 7-3/4 in. |
| Product Weight | 2 lb. 15.2 oz. |
| Product Width | 4 in. |
| Pump/Repair Product Type | Pumps |
| Warranty | 2 Year Consumer, 90 Day Commercial |
| Manufacturer Part Number | 5151089 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 7 of 7 Questions
Newest questions
Q: Is a replacement pump head only available? Or do I need to purchase the entire pump and motor?
a year ago1 Answer
- A: Yes a replacement head is available for this pump. Part number 5164273, which is the upper housing and includes the entire head, but not the motor. Please contact our customer service team at 800-831-0027 and they'll be happy to assist you.a year agoHelpful?
Q: Can roundup be used with this pump
2 years ago1 Answer
- A: Bill, thank you for your interest in the 2.4 GPM high-performance bypass pump from Tractor Supply. All of our pumps are roundup ready. Plus, proper care and maintenance will ensure a longer life.2 years agoHelpful?
Q: will mixing diesel with the water harm the pump
3 years ago1 Answer
- A: Hi aaaax, Here is what I received from our vendor: These pumps are not designed for a diesel surfactant and as such the diaphragm in the pump will eventually fail.3 years agoHelpful?
Q: What do I get for the npt fitting to connect my hoses? This 3/8 is not listed on parts offered by TS.
4 years ago1 Answer
- A: For additional product support, please contact 800-831-0027.4 years agoHelpful?
Q: I can not find a specification for the mounting feet. I am replacing the pump on my fimco tow behind sprayer. What is the distance between and across on the mounting feet?
5 years ago1 Answer
- A: Thank you for your question! 2-1/4” X 3-1/4”5 years agoHelpful?
Q: Does the pump have a on and off switch
6 years ago1 Answer
- A: Yes, there is an on and off switch.5 years agoHelpful?
Q: Can this be used to pump water out of a barrel into a Water Heater for a camp shower?
6 years ago2 Answers
- A: Adding a pressure cut off switch will save battery usage and full time running of this bypass configuration made for continuous use spray applications. For homestyle needs of happy camping, you might check for equivalent cost pumps of 30 to 45 psi at 4-6 gpm with auto off/on pressure switch to run 'as needed' at 2/3 the amps... and battery will last way longer! Or ..GID with a 'transfer pump' for best volume. The lower pressure is kinda nice for filling and wont blow connections like spray pressures can, ya know?5 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 7 of 7 Questions
Newest questions
Q: Is a replacement pump head only available? Or do I need to purchase the entire pump and motor?
a year ago1 Answer
- A: Yes a replacement head is available for this pump. Part number 5164273, which is the upper housing and includes the entire head, but not the motor. Please contact our customer service team at 800-831-0027 and they'll be happy to assist you.a year agoHelpful?
Q: Can roundup be used with this pump
2 years ago1 Answer
- A: Bill, thank you for your interest in the 2.4 GPM high-performance bypass pump from Tractor Supply. All of our pumps are roundup ready. Plus, proper care and maintenance will ensure a longer life.2 years agoHelpful?
Q: will mixing diesel with the water harm the pump
3 years ago1 Answer
- A: Hi aaaax, Here is what I received from our vendor: These pumps are not designed for a diesel surfactant and as such the diaphragm in the pump will eventually fail.3 years agoHelpful?
Q: What do I get for the npt fitting to connect my hoses? This 3/8 is not listed on parts offered by TS.
4 years ago1 Answer
- A: For additional product support, please contact 800-831-0027.4 years agoHelpful?
Q: I can not find a specification for the mounting feet. I am replacing the pump on my fimco tow behind sprayer. What is the distance between and across on the mounting feet?
5 years ago1 Answer
- A: Thank you for your question! 2-1/4” X 3-1/4”5 years agoHelpful?
Q: Does the pump have a on and off switch
6 years ago1 Answer
- A: Yes, there is an on and off switch.5 years agoHelpful?
Q: Can this be used to pump water out of a barrel into a Water Heater for a camp shower?
6 years ago2 Answers
- A: Adding a pressure cut off switch will save battery usage and full time running of this bypass configuration made for continuous use spray applications. For homestyle needs of happy camping, you might check for equivalent cost pumps of 30 to 45 psi at 4-6 gpm with auto off/on pressure switch to run 'as needed' at 2/3 the amps... and battery will last way longer! Or ..GID with a 'transfer pump' for best volume. The lower pressure is kinda nice for filling and wont blow connections like spray pressures can, ya know?5 years agoHelpful?
Similar Items
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
-
Top Rated
-
Top Rated
-
Reviews
Summary of Reviews
The product is described as a powerful and reliable pump that performs well for various spraying applications. Many users praise its great performance, pressure, and ease of installation. However, som...
- English
- German
- French
- Spanish
- Portuguese
- Italian
- Korean
- Chinese
- Japanese
- Arabic
Most Helpful Favorable Review
5 out of 5 stars.
This keep pumping great
4 years ago
I use this pump to pump my sewer on my trailer It work good til it got condom stuck in it. I cleaned it out and it pump good again. Why condom in there I wonder, because I don’t have to use them on my girlfriend cause she pregnant all the time. It’s the same kind my neighbor uses. Why he put it in my drain, he don’t have no wife. That one confused me to this day.
3 people found this helpful
Show Reviews:
Most Helpful Critical Review
3 out of 5 stars.
Buy warranty
6 years ago
Worked for a few days then had an electrical short. Had a warranty and swapped for a new one. Been working good ever since.
3 people found this helpful
Show Reviews:
Customer Images and Videos
- purchase
- quality
- spraying
- price
- small
- satisfaction
- staff
- performance
1 to 4 of 268 Reviews .
1 – 4 of 268 Reviews
Most Recent
Review 1
5 out of 5 stars.
sprayer pump
a year ago
It performs perfectly
Yes, I recommend this product.
Response from Fimco Industries:
a year ago
Fimco Industries
Jeff, thank you for your purchase of the 2.4 GPM high-performance bypass pump from Tractor Supply. We're glad that it's performing perfectly for your needs.
Milton Freewater, Or.
Review 1
5 out of 5 stars.
Fimco 2.4 gpm pump
a year ago
Pump works great. Old pump quit when my tank was half full. Needed one quick. Went to TS. They had this in stock. Flow was opposite so I had to replumb. Another trip to town after it was mounted, but works as needed.
SweepstakesYes
Yes, I recommend this product.
Response from Fimco Industries:
a year ago
Fimco Industries
Thank you for your purchase of the 2.4 GPM pump from Tractor Supply. Glad that after replumbing due to reverse flows, that your new pump is working great for your needs.
Review 1
1 out of 5 stars.
Find something else
a year ago
Seal blew out in 2 weeks
Napoleon Ohio
Reviews 3
3 out of 5 stars.
Bachman Farms
a year ago
Works good but doesn’t last very long
SweepstakesYes
Response from Fimco Industries:
a year ago
Fimco Industries
Dave, sorry you had that issue with the bypass pump. Not sure what's going on, if it's just a pressure thing or not running. But please contact our customer service team at 800-831-0027 and they'll be happy to help you troubleshoot the issue with that pump.
