EMAX 115CFM 115V 10 Amp 1 Micron Coalescing filter Electric Industrial Refrigerated Air Dryer- EDRCF1150115
Online Only
Item # 2095171
Neighbor’s Club Members earn points with purchases.
Online Only
Item # 2095171
Valid 5/11/2026 - 5/25/2026Apply now
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
Our EMAX air dryer is the only energy efficient dryer systems with aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger. Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with Non-corrosive inner and after cooler. Our dryers feature stainless steel heat exchanger for maximum dryer life and less maintenance. Emax Air dryers are UL-CSA approved scroll compressor & electric system for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high CFM flow preventing dryer freeze up. Keep Water, Oil, And Dirt Out of Your Compressed Air Less corrosion of pipes and tools means less downtime Avoid splotches & stains on your projects with proper filtration Energy Efficient Aluminum Refrigerated Air Cooling System Designed for maximum performance and efficiency. Rust Free, Stainless Steel Heat Exchanger Maximum heat transfer, maximum dryer life & less maintenance Refrigerated Air Inlet Inner Cooler Provides trouble free operation for high temp cooling Environmentally Safe Uses 134A refrigerant to prevent damage to the ozone layer Compact And Efficient Great for a 10HP systems 115 CFM Easy To Install Uses 120V single-phase power, no special wiring needed Added Features Auto Drain System Refrigerant Pressure Gauge Outlet Air Baffle Heater Features and benefits Purifies compressed air by chilling to condense moisture Condensate is drained carrying oil & dirt partials away from the air Auto drain system - eliminates the need for daily maintenance Refrigerant pressure - gauge clearly monitors performance of dew point temp (models under 400 CFM) PLC Display (models 400 CFM & above) Outlet air baffle heater - prevents condensation on outlet air piping Heavy duty steel cabinet Trouble free operation refrigerated air inlet inner cooler for high temp cooling Top mounted condenser & fan motor Environmentally friendly 134A refrigerant. 1 year standard warranty-Extended 3 Year warranty with qualifying annual service kit purchase.1 year standard warranty-Extended 3 Year warranty with qualifying annual service kit purchase
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Great for a 10 Horsepower air compressor
- Dimensions: 26 in. x 23 in. x 36 in. (LxWxH) Weight: 180 lb.
- 115 CFM, Max working PSI: 230
- Built in 1 Micron active coalescing filter
- MADE IN GERMANY
- Certifications: ETL, UL, ASME
- ESD - Energy saving device
- Environmentally friendly 134a refrigerant (35 oz.), Refrig. temp switch: 113 F
- 115CFM 60hz 115 Voltage
- Easy To Install- Uses 120V single-phase power, no special wiring needed
- Added features: Auto Drain System, Refrigerant Pressure Gauge, Outlet Air Baffle Heater
- Refrigerant pressure gauge clearly monitors performance of dew point temp (models under 400 CFM
- Outlet air baffle heater prevents condensation on outlet air piping
- Built in auto drain & cyled: Every 5 Min/5 Second drain
- Max rated INLET temp:140 F, Max ambient temp: 122 F
- Full load Amps: 10.87, Amp draw: 15
- Superheat of Thermostatic Expansion Valve: 41-50F
- Evaporating pressure: 29.7PSI, Fan Pressure switch: 130-174PSI
- Security High & Low Pressure switch: 23.2/162.5 PSI
- Water flow valve: 159.5 PSI
