VIAIR Dual Pewter 480C Air Compressor Value pk., 12V, 200PSI
Item # 1383844
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
Providing 200PSI and a 100% duty cycle, the Viair Dual Pewter 480C Value Pack is an ideal air source solution for any air suspension kit, industrial applications, air horns, or off-road pneumatic needs. Each value pack includes two Viair 480C pewter air compressors, two heavy duty 40-amp relays, a 165 PSI cut-on, 200 PSI cut-off pressure switch, and remote mount filter assemblies with mounting hardware. The 100% duty cycle of the dual pewter 480C value pack operates at 100 PSI. The value pack has a combined maximum amp draw of 44 amps.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 200 PSI / 3.53 CFM rating
- 12-volt dual pewter 480C value pack
- Duty Cycle: 100% @ 100 PSI
- Two pewter 480C air compressors with thermal overload protectors included in the value pack
- Max. Working Pressure: 200 PSI
- Max. Air Tank Size: 10.0 gal.
- Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque is 12 to 15 ft. lb.
- Two Air Filter Assemblies
- Two Remote Mount Brackets
- Two Sets of Remote Mount Fittings
- Two Sets of Spare Air Filter Elements
- Two Leader Hose Clips
- Six Air Line Clips with Included Hardware
- Eight Sets of Nuts, Bolts, Washers and Lock Washers
- One Heavy Duty Tube Style Fuse Holder (Up to 60-Amp fuse)
- Two 40-Amp Relays
- One Heavy Duty Pressure Switch (165 PSI on/200 PSI off)
- Two Stainless Steel Braided Leader Hoses with Inline Check Valve
- Air Line for Remote Mount Filter Installation
- Permanent Magnetic Motor
- Combined max. amp draw of dual pewter 480C value pack: 44 Amps
- Ingress Protection Rating: IP67
- Dimensions of each unit in value pack: 10.87 in. L x 4.2 in. W x 6.75 in. H
- Net Weight: 22.10 lb.
