VIAIR 380C Chrome Single Air Compressor Kit, 200 PSI, 12V
Item # 138381899
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair - 380C 200 PSI Chrome Compressor Kit is a truly-rated continuous duty, 12-volt, 200 PSI compressor. The chrome compressor kit is capable of filling a 5.0-gallon tank from 165 PSI to 200 PSI in 3 1/2 min. consistently, while never pulling more than 23 amps of power (@ 13.8 volts). Features of the chrome compressor kit include a standard 1/4 in. stainless steel braided leader hose with 1/4 in. NPT inline check valve and insulated wiring. The included mounting hardware and installation instructions make set-up of the compressor kit simple.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 200 PSI / 1.58 CFM
- 12-volt chrome compressor kit
- Duty Cycle: 100% @ 100 PSI (55% @ 200 PSI)
- Max. working pressure of compressor kit: 200 PSI
- Max. Air Tank Size: 5.0 gal.
- Chrome compressor kit is capable of filling a 5.0 gal. tank from 165 PSI to 200 PSI in 3-1/2 min. consistently while never pulling more than 23 amps of power
- 1/4 in. stainless steel braided leader hose with 1/4 in. NPT inline check valve
- Insulated wiring in the compressor kit for easy installation
- Thermal Overload Protector
- Vibration Isolators
- Mounting Hardware
- Air Line for Remote Mount Air Filter
- Remote Mount Air Filter Assembly
- Two Replacement Air Filter Elements
- Installation Instructions
- Permanent Magnetic Motor
- Max. 12V amp Draw: 23 Amps
- Ingress Protection Rating: IP67
- Dimensions: 9 in. L x 4 in. W x 6.75 in. H
- Net Weight: 8.75 lb.
