Tsurumi 2/3 HP 115V Manual Electric Water Pump
Online Only
Tsurumi 2/3 HP 115V Manual Electric Water Pump
Item # 6012654
$549.99
or
or
Notice:
This Item cannot be shipped to AK, HI.Get everything you need
Neighbor’s Club Members earn points with purchases.
$549.99
or
or
$46/mo.† suggested payments with 12 Months Financing or earn $27 in Rewards+ on this purchase.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Notice:
This Item cannot be shipped to AK, HI.Get everything you need
Neighbor’s Club Members earn points with purchases.
The LB-480 is a slimline submersible pump built for durability and performance. Known for its lightweight, compact design, this pump is easy to transport. Featuring a wear-resistant, semi-vortex impeller and rugged cast iron aluminum housing, the LB-480 can handle high volumes of water and withstand harsh conditions, providing reliable performance with minimal maintenance.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Slimline Design: allowing it to effortlessly fit into an 8" pipe. This design provides easy transport and installation in confined areas. Long Lasting
- Performance: the urethane impeller and wear plates partnered with the dual Silicon Carbide mechanical seal faces, ensure durability, reliability, and longevity.
- Top Discharge: engineered to maximize motor cooling efficiency, enabling continuous duty operation at low levels, and extended dry-run capability.
- Double inside mechanical seals with silicon carbide faces running in an oil filled chamber provide for one the most durable seal designs available.
- Highly efficient, continuous duty air-filled, copper wound motor with class E,B insulation minimizes the cost of operation.
- Residential, commercial, industrial wastewater and site drainage
- Decorative waterfalls and fountains
- Discharge direction is selectable between top and horizontal, which prevents folding or bending of the discharge hose
- 2 in. discharge size
- Head Max at 39.5 ft.
- Indoor or outdoor enclosure type 3
| Brand | Tsurumi |
|---|---|
| Country of Origin | Imported |
| Body Material | Steel |
| Compatible Pipe Material | Steel, Poly, Stainless Steel, PEX, Plastic, PVC |
| Discharge Connection | Threaded Male |
| Discharge Diameter | 2 in. |
| Discharge Rate at 0 ft. | 62.4 ft. |
| Discharge Rate at 10 ft. | 57.6 ft. |
| Engine Displacement | 0.667 HP |
| Features | Slimline Design: allowing it to effortlessly fit into an 8" pipe,Dual Silicon Carbide mechanical seal faces, ensure durability, reliability, and longevity.Top Discharge: engineered to maximize motor cooling efficiency. |
| Hose Diameter | 2 in. |
| Impeller Material | Urethane Impeller |
| Inlet Connection | Threaded Male |
| Inlet Diameter | 2 in. |
| Maximum Flow Rate | 62.4 GPM |
| Maximum Head Lift | 38 ft. |
| Maximum Operating Pressure | 125 PSI |
| Maximum Operating Temperature | 104 deg. |
| Maximum Solids Diameter | 0.236 in. |
| Maximum Suction Lift | 38 ft. |
| Minimum Operating Pressure | 125 PSI |
| Minimum Operating Temperature | 32 deg. |
| Power Type | Electric |
| Product Height | 11.25 in. |
| Product Length | 7.375 in. |
| Product Weight | 21 lb. |
| Product Width | 7.375 in. |
| Pump Mechanism | Centrifugal |
| Motor Type | Highly efficient, continuous duty air-filled, copper wound motor with class E,B insulation |
| Voltage | 115 V |
| Warranty | Two years from the date the unit was first installed or twenty six months from the date of shipment by TSURUMI to wholesaler, whichever comes first. |
| Manufacturer Part Number | LB-480-62 |
