Pacer 2 in. Chemical and Clear Water Transfer, Electric Motor, 5 HP, Three Phase 230-460 V, 240 GPM Max Flow Rate
Item # 6040883
Item # 6040883
Pacer's S' Series Self-Priming Centrifugal pumps are lightweight and chemically resistant for general service on water, salt water, waste water, agricultural chemicals, and mild acids and bases. They feature stainless steel internal and external fasteners and EPDM elastomers The pumps are molded of tough, engineered thermoplastics. All pumps include a built-in check valve, feature easy servicing and during pumping, a self-cleaning double volute keeps pump free of settled solids. It features a 2" port on the inlet and discharge connections with NPT threads for easy connections. It is powered by a 5 hp, three-phase electric motor with flow rates of up to 240 GPM or 75 ft. TDH at 60 Hz for powerful pumping. Please Call Pacer with any chemical compatibility or application questions.
- 240 Max GPM
- 25' Max Suction Lift
- Self Priming after intial Prime
- Polyester Plastic
- EPDM Elastomers
- 5HP 3 Phase Electric Motor
- Carbon Cermaic Shaft Seal
- Molded & Assembled in the USA
- 2" Suction & Discharge Ports
| Brand | Pacer |
|---|---|
| Country of Origin | Made in USA |
| Body Material | Polyester |
| Compatible Pipe Material | Plastic |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 2 in. |
| Discharge Rate at 0 ft. | 240 GPM |
| Discharge Rate at 10 ft. | 220 GPM |
| Engine Displacement | 0 CC |
| Features | Polyester Plastic, EPDM Elastomers, Carbon Ceramic Shaft Seal, 240 Max GPM |
| Horsepower | 5 HP |
| Hose Diameter | 2 in. |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 2 in. |
| Maximum Flow Rate | 240 GPM |
| Maximum Head Lift | 70 ft. |
| Maximum Operating Pressure | 30 PSI |
| Maximum Operating Temperature | 130 deg. F |
| Maximum Suction Lift | 25 ft. |
| Minimum Operating Pressure | 0 PSI |
| Minimum Operating Temperature | 33 deg. F |
| Power Type | Electric |
| Product Height | 20 in. |
| Product Length | 30 in. |
| Product Weight | 65 lb. |
| Product Width | 13 in. |
| Pump Mechanism | Centrifugal |
| Motor Type | 3 Phase Electric |
| Warranty | 1 year limited |
| Manufacturer Part Number | SE2JL D5.0C |
