Industrial Gold 7.5 HP 80 gal. 2-Stage Vertical Air Compressor, 175 PSI, 460V/480V, 3-Phase, 60 Hz, 28 CFM
Item # 192139199
Neighbor’s Club Members earn points with purchases.
Item # 192139199
This item is available online only
Delivery to
For delivery, this item requires a Big & Bulky handling fee.Learn more
Neighbor’s Club Members earn points with purchases.
The Industrial Gold 7.5 HP Air Compressor is designed for heavy commercial and industrial applications. The low RPM pump provides reliable air for your applications and is manufactured for durability and long life. All of our units feature some of the most heavy-duty components found in piston compressors today. From the solid cast-iron pump and full ring base platform, to the industrial grade electric motor, this compressor has you covered.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on air compressors? Check out our air compressor FAQs in the product documents section.
- Air compressor with 28 CFM at 175 PSI
- 80 gal. vertical 200 PSI ASME/CRN air receiver
- Features a TEFC drive motor
- 2 pc. tank and top plate
- Low RPM two-stage solid cast iron pump
- Belt guard after cooler
- Full ring base platform tank
- 460-480V 3 phase
- Silent air compressor silencing system
- 2-grove B width motor pulley
- All UL electrical controls
- ASME tested powder coated steel tank
- Auto start stop
- Automatic tank drain
- Bearings on both ends of the crank shaft
- Centrifugal unloader
- Disk and spring valves
- Fully enclosed belt guard
- Heavy-duty air filter
- Industrial grade electric motor
- Low oil monitor
- Magnetic starter mounted and wired
- Needle bearings, and inserts on rods
- Stainless steel flex air lines
- Swedish steel valves
- Tank discharge ball valve
- Torrington needle bearings
- Vibration pads
| Brand | Industrial Gold |
|---|---|
| Country of Origin | Made in USA |
| Airflow Volume | 28 CFM |
| Air Outlet Size | 3/4 in. |
| Compressor Horsepower | 7.5 HP |
| Lubrication Type | Oil |
| Compressor Maximum PSI | 175 PSI |
| Compressor Tank Capacity | 80 gal |
| Compressor Voltage | 460V/480V |
| Drain System | Manual |
| Drive Type | Electric |
| Features | Cast Iron |
| Fuel Tank Capacity | 80 gal. |
| Phase | Triple |
| Number Of Power Speeds | Single |
| Number Of Wheels | 0 |
| Power Type | Electric |
| Primary Color | Black |
| Primary Material | Steel |
| Product Height | 78 in. |
| Product Length | 36 in. |
| Product Weight | 750 lb. |
| Product Width | 24 in. |
| Pump Material | Cast iron |
| Tank Style | Vertical |
| Warranty | 1 Year |
| Manufacturer Part Number | CI7523E80V-CI10-480-P |
