Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting
$9.99
Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting
Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting
Item # 108269599
$9.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
$9.99
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting helps to permit the free flow of liquids for tank or drum drainage or filling. Made from polypropylene construction, this bulkhead fitting is designed to be resistant to chemicals for long-lasting use. The poly bulkhead fitting is also NSF61 and NSF372 certified, and includes an EPDM washer for convenience.
- Includes an EPDM washer for convenience
- Comes as a 1/2 in. female NPT bulkhead fitting
- Polypropylene bulkhead fitting construction is resistant to chemicals for durability
- Helps permit the free flow of liquids for tank or drum drainage or filling
- NSF61 and NSF372 certified bulkhead fitting
- Hole size measures 1-1/4 in.
| Brand | Green Leaf Inc. |
|---|---|
| Country of Origin | Made in USA |
| Compatibility | Universal |
| Connection Type | Female |
| End Type | Female-female |
| Features | Universal |
| Inlet Diameter | 0.5 in. |
| Maximum Operating Pressure | 75 PSI |
| Outlet Diameter | 1.25 in. |
| Package Quantity | 1 |
| Primary Material | Polypropylene |
| Product Height | 3.75 in. |
| Product Length | 3.75 in. |
| Product Weight | 0.134 lb. |
| Product Width | 2 in. |
| Manufacturer Part Number | TF 12 P-E |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 8 of 8 Questions
Newest questions
Q: What is the minimum wall thickness? and maximum.
5 months ago1 Answer
- A: The Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting (TF12P-E) is designed for use with tanks having the following wall thickness specifications: Minimum Wall Thickness: 1/16 inch. Maximum Wall Thickness: 1/2 inch.5 months agoHelpful?
Q: What size hole saw to use to cut hole?
a year ago1 Answer
- A: Comes as a 1/2 in. female NPT bulkhead fitting Inlet Diameter 0.5 in. Outlet Diameter 1.25 in.11 months agoHelpful?
Q: What is the maximum operating temperature of this bulkhead fitting?
a year ago1 Answer
- A: Hi, Thanks for your question. The maximum service temperature for a polypropylene fitting is typically around 180°F (82°C). Beyond this temperature, the performance of the material may be compromiseda year agoHelpful?
Q: What is the maximum depth of penetration? I.e. max wall thickness
a year ago1 Answer
- A: Inlet Diameter 0.5 in. Maximum Operating Pressure 75 PSI Outlet Diameter 1.25 in.a year agoHelpful?
Q: Does this have female threading (ig for me to attach a hog nipple)?
2 years ago1 Answer
- A: Hi, Here is the information we received from the vendor- "Yes the TF12PE has ½” female NPT threads."2 years agoHelpful?
Q: What is the external threads in this?
3 years ago1 Answer
- A: Hi Jaym, Im not sure what your asking can you restate the question?3 years agoHelpful?
Q: Can this fitting be used on poly fuel tank?
7 years ago1 Answer
- A: This is not recommended. The polypropylene material will hold up to fuel but the EDPM sealing gasket will deteriorate rather quickly.7 years agoHelpful?
Q: What size pilot hole do you drill in the barrel to install this fitting? I think an inch and 3/8 will work. Am I correct.
8 years ago1 Answer
- A: The hole size we recommend to drill is 1 1/4".8 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 8 of 8 Questions
Newest questions
Q: What is the minimum wall thickness? and maximum.
5 months ago1 Answer
- A: The Green Leaf Inc. 1/2 in. Polypropylene Bulkhead Fitting (TF12P-E) is designed for use with tanks having the following wall thickness specifications: Minimum Wall Thickness: 1/16 inch. Maximum Wall Thickness: 1/2 inch.5 months agoHelpful?
Q: What size hole saw to use to cut hole?
a year ago1 Answer
- A: Comes as a 1/2 in. female NPT bulkhead fitting Inlet Diameter 0.5 in. Outlet Diameter 1.25 in.11 months agoHelpful?
Q: What is the maximum operating temperature of this bulkhead fitting?
a year ago1 Answer
- A: Hi, Thanks for your question. The maximum service temperature for a polypropylene fitting is typically around 180°F (82°C). Beyond this temperature, the performance of the material may be compromiseda year agoHelpful?
Q: What is the maximum depth of penetration? I.e. max wall thickness
a year ago1 Answer
- A: Inlet Diameter 0.5 in. Maximum Operating Pressure 75 PSI Outlet Diameter 1.25 in.a year agoHelpful?
Q: Does this have female threading (ig for me to attach a hog nipple)?
2 years ago1 Answer
- A: Hi, Here is the information we received from the vendor- "Yes the TF12PE has ½” female NPT threads."2 years agoHelpful?
Q: What is the external threads in this?
3 years ago1 Answer
- A: Hi Jaym, Im not sure what your asking can you restate the question?3 years agoHelpful?
Q: Can this fitting be used on poly fuel tank?
7 years ago1 Answer
- A: This is not recommended. The polypropylene material will hold up to fuel but the EDPM sealing gasket will deteriorate rather quickly.7 years agoHelpful?
Q: What size pilot hole do you drill in the barrel to install this fitting? I think an inch and 3/8 will work. Am I correct.
8 years ago1 Answer
- A: The hole size we recommend to drill is 1 1/4".8 years agoHelpful?
Similar Items
-
-
-
-
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
-
-
Items You May Like
-
-
-
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
-
-
-
Customers Also Bought
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
-
Top Rated
-
-
Top Rated
Reviews
Customer Images and Videos
- small
- installation
- flexibility
- for rainy weather
- information
- instructions
- large
- metal
1 to 4 of 22 Reviews .
1 – 4 of 22 Reviews
Most Recent
KY
Review 1
5 out of 5 stars.
thx
2 years ago
good peice and quick delivery
Yes, I recommend this product.
South Carolina
Reviews 2
5 out of 5 stars.
Great product
2 years ago
Works great and allows you to use self watering device for animals
2023 Q4 SweepstakesYes
Review 1
5 out of 5 stars.
Bucket application
2 years ago
Used it on a 5gal medium thickness un-pressurized polyethylene bucket with 5 gal of water in it, the seals didn't leak and it was easy to install. The threads worked very well for me also.
Yes, I recommend this product.
East Texas
Review 1
4 out of 5 stars.
No Install Info Anywhere
2 years ago
Great USA made fitting but no instructions anywhere. It took me valuable time to hunt down the hole info. Tractor Supply, you need to advise the hole size required for install. Put it in the product description please!!!! Otherwise you would have a 5 star.
Yes, I recommend this product.
