Green Leaf Inc. 3/4 in. Polypropylene Bulkhead Fitting
$16.99
Green Leaf Inc. 3/4 in. Polypropylene Bulkhead Fitting
Green Leaf Inc. 3/4 in. Polypropylene Bulkhead Fitting
Item # 212560299
$16.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
$16.99
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Green Leaf Inc. 3/4 in. Polypropylene Bulkhead Fitting helps to permit the free flow of liquids for tank or drum drainage or filling. Featuring an EPDM washer, these bulkhead fittings can be utilized for a variety of agricultural, plumbing and industrial liquid-handling solutions. Highly durable and chemical-resistant, this poly bulkhead fitting is designed to hold up for heavy-duty agricultural applications.
- Comes as a 3/4 in. female NPT bulkhead fitting size
- Outlet flange and inside bolt seal double seal flange are both full port
- Polypropylene construction is chemical-resistant for durability
- Comes with an EPDM washer for convenience
- Helps permit the free flow of liquids for tank or drum drainage or filling
- Hole size measures 1-3/8 in.
- Manufactured in a variety of sizes ranging from 1/2 in. to 4 in.
- Utilized for a variety of agricultural, plumbing and industrial liquid-handling solutions
- Made in the U.S.A.
- External thread and nut are left-hand threads; internal thread is FPT
- For use with tanks having a wall thickness of 1/16 in. to 1/2 in.
- FDA approved grade material for safe use
- Both NSF61 and NSF372 certified bulkhead fitting
| Brand | Green Leaf Inc. |
|---|---|
| Country of Origin | Made in USA |
| Compatibility | Universal |
| Connection Type | Female |
| End Type | Female-female |
| Features | Chemical Resistant |
| Inlet Diameter | 1-1/4 in. |
| Maximum Operating Pressure | 75 PSI |
| Outlet Diameter | 1-3/8 in. |
| Package Quantity | 1 |
| Primary Material | Polypropylene |
| Product Height | 3.88 in. |
| Product Length | 3.88 in. |
| Product Weight | 0.134 lb. |
| Product Width | 2.38 in. |
| Manufacturer Part Number | TF 34 P-E |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 17 Questions
Newest questions
Q: How tall is the top lip of bulkhead? Need top lip to be thinner than 1/4" to allow water to pass over without flooding.
2 months ago1 Answer
- A: Hello, the flange (top lip) of the Green Leaf TF 34 P-E bulkhead fitting has a thickness of approximately 1/4 inch, which may be right at your limit for preventing a flood. While the exact lip height can vary slightly by production batch, these heavy-duty polypropylene fittings are designed with thick, robust flanges and include a sizable EPDM gasket that adds additional height when installed.2 months agoHelpful?
Q: What size hole is needed to install this into a water trough?
4 months ago1 Answer
- A: Hello, thank you for your question. Per the vendor, "The hole size needed is 1 3/8"."4 months agoHelpful?
Q: Will this allow 3/4"pipe to slip through
10 months ago2 Answers
- A: Hello, thank you for your question. Per the vendor, "Unfortunately a 3/4” pipe cannot slide through the fitting. Rather, it has 3/4”female pipe threads in which you can attach pipe or hose onto."9 months agoHelpful?
Q: What is the size of the inside female threads on this
2 years ago1 Answer
- A: Hi there, According to the vendor: The threads are ¾” female NPT. Have a great day.2 years agoHelpful?
Q: will this hook up to a garden hose to get expelling water away from the tank?
2 years ago1 Answer
- A: Hi, Here is the information we received back from the vendor- "The TF34PE has female NPT threads. The end user would need a male adapter x garden hose adapter to hook up a garden hose to expel water. The adapter the customer needs is TSC sku 211052699."2 years agoHelpful?
Q: How big of a hole do I have to make for the 1/2" and the 3/4"?
3 years ago1 Answer
- A: Hi, For such a specific inquiry, please reach out to Green Leaf Inc. directly at Phone: 1 (800) 654-9808 OR https://green-leaf.us/help-support/3 years agoHelpful?
Q: What temperature is this rated up to?
3 years ago1 Answer
- A: Use for temperature up to 140°F (see physical properties) This information is provided as a guide. Due to infinite end use possibilities, Green Leaf, Inc. cannot assume liability related to the suitability of our products for end use. It must be the responsibility of the end user to independently analyze our products and make that determination.3 years agoHelpful?
Q: Is this product lead free?
3 years ago1 Answer
- A: Material: • Body and Nut are Polypropylene (P) • Friction washer is Polyethylene • Sealing washer is either Buna (B), EPDM (E) or Santoprene. Nylon, Buna and Polyethylene used in manufacturing are FDA approved grade.3 years agoHelpful?
Q: Is this bulkhead a slip to slip fitting on the inside or is it threaded?
3 years ago1 Answer
- A: Hi McLovin21, Thanks for the question. See below- External thread and nut are left-hand threads; internal thread is FPT Both NSF61 and NSF372 certified bulkhead fitting3 years agoHelpful?
Q: can i get this item delivered to Atmore al store
4 years ago1 Answer
- A: You would need to contact the TS location directly for assistance with this inquiry.4 years agoHelpful?
1 - 10 of 17 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 17 Questions
Newest questions
Q: How tall is the top lip of bulkhead? Need top lip to be thinner than 1/4" to allow water to pass over without flooding.
2 months ago1 Answer
- A: Hello, the flange (top lip) of the Green Leaf TF 34 P-E bulkhead fitting has a thickness of approximately 1/4 inch, which may be right at your limit for preventing a flood. While the exact lip height can vary slightly by production batch, these heavy-duty polypropylene fittings are designed with thick, robust flanges and include a sizable EPDM gasket that adds additional height when installed.2 months agoHelpful?
Q: What size hole is needed to install this into a water trough?
4 months ago1 Answer
- A: Hello, thank you for your question. Per the vendor, "The hole size needed is 1 3/8"."4 months agoHelpful?
Q: Will this allow 3/4"pipe to slip through
10 months ago2 Answers
- A: Hello, thank you for your question. Per the vendor, "Unfortunately a 3/4” pipe cannot slide through the fitting. Rather, it has 3/4”female pipe threads in which you can attach pipe or hose onto."9 months agoHelpful?
Q: What is the size of the inside female threads on this
2 years ago1 Answer
- A: Hi there, According to the vendor: The threads are ¾” female NPT. Have a great day.2 years agoHelpful?
Q: will this hook up to a garden hose to get expelling water away from the tank?
2 years ago1 Answer
- A: Hi, Here is the information we received back from the vendor- "The TF34PE has female NPT threads. The end user would need a male adapter x garden hose adapter to hook up a garden hose to expel water. The adapter the customer needs is TSC sku 211052699."2 years agoHelpful?
Q: How big of a hole do I have to make for the 1/2" and the 3/4"?
3 years ago1 Answer
- A: Hi, For such a specific inquiry, please reach out to Green Leaf Inc. directly at Phone: 1 (800) 654-9808 OR https://green-leaf.us/help-support/3 years agoHelpful?
Q: What temperature is this rated up to?
3 years ago1 Answer
- A: Use for temperature up to 140°F (see physical properties) This information is provided as a guide. Due to infinite end use possibilities, Green Leaf, Inc. cannot assume liability related to the suitability of our products for end use. It must be the responsibility of the end user to independently analyze our products and make that determination.3 years agoHelpful?
Q: Is this product lead free?
3 years ago1 Answer
- A: Material: • Body and Nut are Polypropylene (P) • Friction washer is Polyethylene • Sealing washer is either Buna (B), EPDM (E) or Santoprene. Nylon, Buna and Polyethylene used in manufacturing are FDA approved grade.3 years agoHelpful?
Q: Is this bulkhead a slip to slip fitting on the inside or is it threaded?
3 years ago1 Answer
- A: Hi McLovin21, Thanks for the question. See below- External thread and nut are left-hand threads; internal thread is FPT Both NSF61 and NSF372 certified bulkhead fitting3 years agoHelpful?
Q: can i get this item delivered to Atmore al store
4 years ago1 Answer
- A: You would need to contact the TS location directly for assistance with this inquiry.4 years agoHelpful?
1 - 10 of 17 Questions
Similar Items
-
-
-
-
-
-
-
-
-
-
Top Rated
-
-
Items You May Like
-
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
Customers Also Bought
-
-
Top Rated
-
-
-
-
-
-
-
-
-
-
Reviews
- connections
- for rainy weather
- growth
- price
- purchase
- quality
1 to 4 of 13 Reviews .
1 – 4 of 13 Reviews
Most Recent
Maine
Review 1
1 out of 5 stars.
Bad advise
11 months ago
I brought the broken part to your Bangor store. The clerk said it was 1/2' and they didn't have it, but they had one in their Holden store. I went out of my way to Holden and the clerk without measuring said it was a 3/4" which they didn't have and he ordered online. After trying to install part to a water tank, I realize the first clerk was right.
SweepstakesYes
Louisiana
Review 1
2 out of 5 stars.
Bulkhead Fitting
2 years ago
The product was fine, but the product description was incorrect. The OD of the fitting was larger than size stated in the description. It would not fit the tank without drilling a larger size hole. I carefully checked the stated product information against the hole size on the tank prior to placing my order. The
2023 Q4 SweepstakesYes
Yes, I recommend this product.
Austin TX
Reviews 6
5 out of 5 stars.
Gets the job done
2 years ago
Works as expected
2023 Sweepstakes EntryYes
Yes, I recommend this product.
Tahlequah, OK
Review 1
5 out of 5 stars.
Quality Fitting
7 years ago
Just what I needed, well made part, sealed perfectly in a rain barrel. Don't over-tighten!
Yes, I recommend this product.
