Grape Solar 100-Watt Off-Grid Solar Panel Kit
5.03 Reviews
Item # 1204528
$197.99
Sale
Was$219.99
Save $22.00
Neighbor’s Club Members earn points with purchases.
5.03 Reviews
Item # 1204528
$197.99
Sale
Was$219.99
Save $22.00
New Cardmembers earn a $20 Reward‡ with qualifying purchase of $20 or more plus earn 5% in Rewards+ on this purchase. Valid through 6/28/26.Apply now
This item is available online only
Out of stock delivering to
37027
This item is not available
Search Stores
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
Keep your equipment charged and ready with the Grape Solar 100-Watt Off-Grid Solar Panel Kit. This durable panel is ideal for a variety of DC applications, including RVs, 12-Volt battery charging, boats, small pumps and LED lights. Constructed with high-efficiency mono-crystalline solar cells, this easy-to-install kit lasts for years and is virtually maintenance free. The anodized aluminum frame and sealed junction box make the panel weatherproof for outdoor use. Add up to 4 additional panels for more power. The system provides 300-Watt Hours or 25 Amp Hours of charge per average day. Compatible with deep cycle batteries including lithium-ion. The kit Includes: 1-piece Grape Solar GS-Star-100W 100-Watt mono-crystalline solar panel, a 40 Amp Grape Solar Comet charge controller, cables and manual.Contact Manufacturer
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Ideal for DC applications and perfect for RVs, boats, 12-volt battery charging and small pumps
- Mono-crystalline panel with anodized aluminum frames and tempered glass for outdoor use and superior performance
- Panel's bypass diodes reduce shade losses in series strings
- 40 amp grape solar comet charge controller allows you to add up to four more panels in parallel, for a total of 500w (use part # GS-100-EXP)
- Kit comes with all cables and connectors for quick and easy set-up
- Battery not included, a minimum of one 12-volt deep cycle battery (50 Ah minimum size) is necessary to use this kit
- Anodized frame and sealed junction box make a weatherproof panel
- Provides 300-watt hours or 25 amp hours of charge per average day
| Brand | Grape Solar |
|---|---|
| Country of Origin | Imported |
| Amperage | 40A |
| Connection Type | Other |
| Current at Maximum Power | 5.23A |
| Energy Output Per Hour Per 1 Day Charge | 300 Wh |
| Features | None |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40 deg.C |
| Mounting Location | Other |
| Mounting Type | None |
| Number Of Cells | 36 |
| Number of Panels | 1 |
| Open Circuit Voltage | 23.1V |
| Power Tolerance | 600V |
| Primary Material | Other |
| Product Height | 28.15 in. |
| Product Length | 31.89 in. |
| Product Weight | 15.4 lb. |
| Product Width | 1.38 in. |
| Short Circuit Current | 6.13A |
| Solar Panel Type | Polycrystalline silicon panel |
| Wire Size | 10 AWG |
| Voltage | 12V |
| Voltage at Maximum Power | 19.12V |
| Warranty | Panel: 5 year limited product warranty on material/workmanship, 25 year warranty on > 80% power output and 10 year warranty on > 90% power output. Charge Controller: 1 year limited warranty for defects in workmanship and materials |
| Wattage | 100W |
| Wire Type | Stranded copper |
| Manufacturer Part Number | GS-100-KIT |
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 17 Questions
Newest questions
Q: Can this charge a battery for a small winch that pulls 2500lbs and some LED lights?
a year ago1 Answer
- A: Hello, thank you for your question. To accurately answer whether the Grape Solar 100-Watt Off-Grid Solar Panel Kit can be used for this application we would need more information like the power consumption of the winch and the LED lights.a year agoHelpful?
Q: Is conroler sold sepertly
Anonymousa year ago1 Answer
- A: Hello, Thank you for your question. The kit Includes: 1-piece Grape Solar GS-Star-100W 100-Watt mono-crystalline solar panel, a 40 Amp Grape Solar Comet charge controller, cables and manual.a year agoHelpful?
Q: How long is delivery time?
a year ago1 Answer
- A: Hello, Thank you for your question. This can vary based on your location, inventory availability and where the item is shipping from. This product is currently unavailable for purchase at this time. Please reach out to the Tractor Supply Customer Service team to find out more about restock information and delivery times to your local area. ***Tractor Supply Customer Service*** 877-718-6750 7:00 am - 9:00 pm CST (Mon. - Sat.) 8:00 am - 7:00 pm CST (Sun.) Closed Easter Sunday and Christmas Daya year agoHelpful?
Q: Can exterior lighting be connected with this unit?
2 years ago1 Answer
- A: Hi, For such a specific product inquiry, please contact the manufacturer directly. We have listed their information below. ***GRAPE SOLAR*** https://grapesolar.com/contact/ OR 1-541-349-9000 / Phone2 years agoHelpful?
Q: Will this plug into my ZAMP connector on my rv/trailer
3 years ago1 Answer
- A: Hi! Thank you for reaching out. This durable panel is ideal for a variety of DC applications, including RVs, 12-Volt battery charging, boats, small pumps and LED lights.3 years agoHelpful?
Q: Why would I need a minimum 50Ah battery if my power requirements are far less than that?
4 years ago1 Answer
- A: For technical support, please contact 1-877-264-1014.4 years agoHelpful?
Q: Does this kit have enough capacity to power 2 battery tenders and occasionally a small led light?
4 years ago1 Answer
- A: For additional product support, please contact 1-877-264-1014.4 years agoHelpful?
Q: If I have 5 100 W panels would that be enough power to run a small refrigerator
4 years ago1 Answer
- A: That would depend on the how much is needed for the refrigerator. This product provides 300-watt hours or 25 amp hours of charge per average day4 years agoHelpful?
Q: Can this be directly wired to a power inverter? It would be used to run a tv while ice fishing.
5 years ago1 Answer
- A: Yes, a power can be used with this product.5 years agoHelpful?
Q: I need to be able to charge laptops and phones to work off-grid. If I were to get a solar kit, would this be enough? Would I also need to get an inverter, or if I get a "car charger" inverter, could I plug that directly into this kit?
5 years ago1 Answer
- A: The kit is designed to be used on a 12V battery system. We do not sell batteries or inverters via Tractor Supply.5 years agoHelpful?
1 - 10 of 17 Questions
