Fimco 45 gal. 4-Nozzle 12 V Trailer Sprayer
Item # 233686099
Get everything you need
Neighbor’s Club Members earn points with purchases.
Valid 5/15/2026 - 7/5/2026Apply now
Shopping at
Grassland (franklin) TN
Delivery to
37027
This is a Big & Bulky item.
Pickup Nearby at ASHLAND CITY TN(23) miles Free
Ship to store at Franklin TN
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Fimco 45 Gallon 4-Nozzle 12V Trailer Sprayer is a powerful and versatile spraying solution for various applications, including agriculture, landscaping, and pest control. This compact and portable sprayer is designed to be towed behind a utility vehicle or ATV, making it easy to transport and use in remote areas. The UV resistant, molded polymer tank has a 5 inch tethered lid for easy access and is completely drainable. This model lawn and garden sprayer features the best in class High Flo High Performance 2.4 GPM 12 Volt Pump with inline fuse protection. The Deluxe Pistol Grip Spray Wand with an adjustable spray pattern brass tip distributes up to 40 feet horizontal spray, 25 feet of vertical spray and comes with 25 feet of 3/8 inch hose. The 4 Nozzle Folding Steel Boom offers 10 feet of total spray coverage and our FIMCO exclusive manifold with pressure gauge conveniently places pressure control and boom operation at your fingertips to fine tune your spray pattern. Large durable 16" diameter rubber turf tires provide a smooth ride for easy pulling over any type of terrain. This tow-behind sprayer allows easy, accurate and consistent liquid application of lawn care products. With the Fimco 45 Gallon 4-Nozzle 12V Trailer Sprayer, you can effectively and efficiently tackle a wide range of spraying tasks.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on sprayers? Check out our guide on agricultural and lawn sprayers in the product documents section.
- 2.4 GPM High Flo High Performance pump features an internally fan cooled motor as well as chemically resistant valves and diaphragms which increase durability ensuring longer pump life
- 25 Feet of hose gives you the length necessary to reach tight areas, around buildings and other obstacles
- 4 nozzle folding boom with TeeJet AIXR air induction tips covers 10' swath
- Deluxe pistol grip spray wand delivers up to 40 feet of horizontal spray and 25 feet of vertical spray and features an ergonomic polymer handle and precision brass tip
- Durable 45 Gallon blow molded tank features UV stabilizers and molded drain port and 5 inch lid for easy filling
- Made for these types of applications: weed control, pest control, fungus control, fertilizing, watering
| Brand | Fimco |
|---|---|
| Country of Origin | Made in USA |
| Boom Maximum Spray Width | 10 ft |
| Boom Nozzle Count | 4 |
| Boom Style | Folding Boom |
| Chemical Compatibility | Herbicide, Grass Killer, Pesticide, Most Liquids, Weed Killer, Repellents, Insecticide, Repellent, Fungicide |
| Features | Handgun and 4 Nozzle Boom Included |
| Hose Diameter | 0.375 in. |
| Hose Length | 25 ft. |
| Maximum Flow Rate | 2.4 GPM |
| Maximum Operating Pressure | 60 PSI |
| Power Type | 12 Volt |
| Product Height | 30 in. |
| Product Length | 62 in. |
| Product Weight | 103 lb. |
| Product Width | 36 in. |
| Pump Type | Diaphragm |
| Boom Width | 7.5 ft |
| Tank Capacity | 45 gal. |
| Spray Method | Boom Spraying (Precision), Spot Spraying |
| Tank Material | Polyethylene |
| Warranty | 2 Year Pump, 1 Year balance |
| Manufacturer Part Number | 5303635 |
Q: Are hangers available for the spray boom on the 45 gallon tow behind sprayer
17 days ago- A: Hello, finding the perfect fit for your equipment is easy. Just pop the name of the accessory or attachment you're looking for into the search bar on the Tractor Supply website! It’s the fastest way to see everything we have in stock to help you get the job done. If you have trouble finding the part on the TSC website, you might want to try reaching out to the manufacturer directly.15 days agoHelpful?
Q: I have a leak where the tank clamps to the trailer. Can this be fixed?
10 months ago- A: Please contact our customer service team at 800-831-0027 for assistance with this issue.10 months agoHelpful?
Q: I have a county line rototiller hooked up to my john deer 4066r Can I hook sprayer without removing the tiller
a year ago- A: This is a trailer sprayer, so it would need to hook on to the back of your tractor.a year agoHelpful?
Q: Can you put a different chemical tank on it that mixes on exit
a year ago- A: Mike, unfortunately, we do not have anything available that will mix on exit. that would be something you would have to fabricate. We have been looking into a system that will allow a sprayer to do that, but as of right now, we don't have anything and not sure if we will.a year agoHelpful?
Q: How do you store in winter to keep the tank from cracking
a year ago- A: Tank Care & Maintenance Warning: Do not use the tank as a container for fuel oils, kerosene, gasoline or any other petroleum distillate product. All polyolefins are softened and permeated by such products. In an enclosed area the vaporization of these materials from the outside surface of the tank could create a dangerous condition. The tank should not be used as a pressure vessel nor used with chemicals or solutions having a weight of more than 12 pounds per gallon. Store the tank in a dry dark place when not in use. Storage out of sunlight will prolong the life of the tank. Do not drop, strike or kick the tank, especially at low temperatures. Tanks become brittle and are subject to cracking at temperatures below 20° Fahrenheit. Always flush the tank with water and a neutralizing agent at the end of each use, to prevent contamination of solutions. Winter Storage Prepare the sprayer for end-of-season storage by running RV antifreeze through the system. This will keep internal parts lubricated, protect against corrosion and keep the unit from freezing. Note: RV antifreeze is non-toxic and biodegradable and generally safer for the environment than automotive antifreeze. Before storing your sprayer for winter or long term storage, thoroughly clean and drain it as much as possible. Then pour enough pink RV antifreeze into the tank so that when the pump is turned on you can pump the antifreeze throughout the entire plumbing system, including the bypass. Make sure to operate the boom and handgun until you see pink fluid spraying from the nozzles. Leave any remaining antifreeze in the tank. Before your next usage, rinse the antifreeze from the sprayer with clean water. It is nearly impossible to drain all of the water from the sprayer and any trapped water can freeze in cold weather and damage parts of the sprayer. Pumping the antifreeze through the system will displace the water and help prevent this damage. Removing from storage: drain the antifreeze. Fill the tank with fresh water and run through the system. Dispose of antifreeze and flush water properly.a year agoHelpful?
Q: Can I remove the hand sprayer?
Anonymousa year ago- A: Matthew, yes you can remove the hand sprayer. All you would have to do is shut off the valve on that outlet to shut it off. You can also call our customer service team at 800-831-0027 and they'll be more than happy to send you a plug as well, as we have those in the office and we would just mail it out to you. You would just replace the barb in the cap with the plug and then that would also shut off that outlet.a year agoHelpful?
Q: Using my zero turn mower, how do I hook up pump electrically? Does it clamp onto my 12V battery or do I need some type of connector?
2 years ago- A: Erik, thank you for your interest in the 45-gallon trailer sprayer from Tractor Supply. The sprayer comes with a lead wire with battery clamps to hook it up to your battery. A stand-alone battery can also be used, any 12-volt rechargeable battery will work.2 years agoHelpful?
Q: Can you spray a smaller swath than 10 feet?
2 years ago- A: About the only way you could spray less than the 120" spray coverage would be to install shut off valves inline on the nozzle harness to shut off the end nozzles or to shut two nozzles on one side of the boom and either spray on the left or the right. Then you would be able to spray about half that swath.2 years agoHelpful?
Q: Will this plug into a 12V outlet in my UTV?
2 years ago- A: Barry, if you're referring to something like a cigarette lighter outlet, you can purchase the lead wire with cigarette lighter adapter and then you can hook up the sprayer.2 years agoHelpful?
Q: Does this have a regulator to control pressure?
2 years ago- A: This sprayer has a manifold coming off the outlet side of the pump with 3 connections. One to the spray gun, one to the boom and one is a bypass (marked Press Adj). With the one for the bypass, a hose comes off running back to the tank. You regulate your pressure with this line. The more open, the less the pressure, the more closed, the higher the pressure.2 years agoHelpful?
Similar Items
Items You May Like
Customers Also Bought
Reviews
Customer Images and Videos
- setup
- purchase
- material
- packaging
- price
- satisfaction
- accuracy
- spraying
Fimco's quality? Poor at best.
No, I do not recommend this product.
Please reach out to our customer support team directly at 800-831-0027 if there is anything we can do for you.
To clarify why the 20-inch height requirement is located on the boom parts breakdown page: this specification is a variable determined entirely by the specific nozzle tips and spray angles used on this exact boom assembly. Because the required height can be affected by height of grass, weeds and even the towing vehicle hitch can vary widely and changes depending on the nozzle part configuration to achieve a perfect, overlapping pattern, it is kept alongside the technical breakdown of the boom parts rather than the general frame assembly steps.
We appreciate your insights as they help us continually improve our manuals and quality control.
Weak pump
No, I do not recommend this product.
Nice Spray Rig -- Very Good Right out of the Box
Yes, I recommend this product.
Home use only
No, I do not recommend this product.
