Dial Manufacturing Inc. 3/4 HP 2 Speed Evaporative Cooler Motor, 115V
Dial Manufacturing Inc. 3/4 HP 2 Speed Evaporative Cooler Motor, 115V
Item # 1081060
$159.99
Neighbor’s Club Members earn points with purchases.
Dial Manufacturing Inc. 3/4 HP 2 Speed Evaporative Cooler Motor, 115V
Item # 1081060
$159.99
New Cardmembers earn a $50 Reward‡ with qualifying purchase of $50 or more plus earn 5% in Rewards+ on this purchase. Valid through 10/11/26.
Out of stock at or near
Grassland (franklin) TN
Out of stock delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Dial Manufacturing, Inc. 3/4 HP 2 Speed Evaporative Cooler Motor has UL-recognized components for safety. Automatic thermal overload protects against overheating. Can be automatically controlled with a cooler thermostat or with manual wall switch (both sold separately).
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Permanently Lubricated Ball Bearings
- Automatic Reset Thermal Overload
- All Copper Windings
- NEMA 56Z Frame
- 1 Year Limited Warranty
| Brand | Dial Manufacturing Inc. |
|---|---|
| Country of Origin | Imported |
| Compatibility | Evaporative Coolers |
| Drive Shaft | Horizontal |
| Horsepower | 3/4 HP |
| Indoor/Outdoor | Indoor |
| Number of Speeds | 2 |
| Power Type | Electric |
| Primary Material | Steel |
| Product Height | 7 in. |
| Product Length | 11 in. |
| Product Weight | 20.97 lb. |
| Product Width | 7 in. |
| Ring Diameter | 2.5 in. |
| Shaft Diameter | 0.5 in. |
| Shaft Length | 1.675 in. |
| Voltage | 115V |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | 2206 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Is this motor reversible?
5 years ago1 Answer
- A: The motor is designed to spin one direction, clockwise. It is not reversible.5 years agoHelpful?
Q: What size shaft
5 years ago1 Answer
- A: The motor shaft size is 1/2”. They are probably asking to see what size motor pulley they should use, which we recommend a 3-3/4” x 1/2” bore.5 years agoHelpful?
Q: cw or ccw
5 years ago1 Answer
- A: Clockwise5 years agoHelpful?
Q: does this motor come with a mount
5 years ago1 Answer
- A: This item comes by itself, no base. The base, PN 2724 comes separately.5 years agoHelpful?
Q: what are the 2 rpms of the motor
5 years ago1 Answer
- A: 1140 and 1725 RPM5 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Is this motor reversible?
5 years ago1 Answer
- A: The motor is designed to spin one direction, clockwise. It is not reversible.5 years agoHelpful?
Q: What size shaft
5 years ago1 Answer
- A: The motor shaft size is 1/2”. They are probably asking to see what size motor pulley they should use, which we recommend a 3-3/4” x 1/2” bore.5 years agoHelpful?
Q: cw or ccw
5 years ago1 Answer
- A: Clockwise5 years agoHelpful?
Q: does this motor come with a mount
5 years ago1 Answer
- A: This item comes by itself, no base. The base, PN 2724 comes separately.5 years agoHelpful?
Q: what are the 2 rpms of the motor
5 years ago1 Answer
- A: 1140 and 1725 RPM5 years agoHelpful?
Similar Items
-
-
-
-
Top Rated
-
Top Rated
-
-
-
-
-
-
-
Items You May Like
-
Top Rated
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
Customers Also Bought
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
-
-
Reviews
1 to 1 of 5 Reviews .
1 – 1 of 5 Reviews
Most Recent
Anonymous
Review 1
5 out of 5 stars.
Swamp cooler motor dropped right in
5 years ago
This motor was purchased to replace a failed swamp cooler motor. It was an exact fit, the wiring was easy, and it works fine. It was off the shelf at the local Tractor Supply.
