Culvert HDPE 12 in. x 20 ft. Corrugated Pipe, HDPE 1220

SKU: 133085499
Enter Zip Code for price
Product price

Save Up To
See price at checkout
Product Rating is 4.7
4.7
 (6)

Quantity

TSC of plant city #515
1803 jim redman pkwy
plant city, FL 33563
(813) 707-1185
TSC of plant city #515
1803 jim redman pkwy
plant city, FL 33563
(813) 707-1185
Check Availability at Other Stores
Standard Delivery Not Available to
This item will ship within 4 days.
Change Delivery Location
Note: This product cannot be shipped to AZ,CA,CO,ID,MT,NV,NM,OR,UT,WA,WY

Item Information

Culvert HDPE 12 in. x 20 ft. Corrugated Pipe

  • Manufactured with smooth interior allowing for more efficient flow
  • Designed with a bell and spigot with a gasket for a water tight joint
  • Excellent abrasion and corrosion resistance
  • Long term drainage solution
  • High Density Polyethylene
  • Our culverts are DOT approved. They will support the weight of any DOT approved vehicle when installed correctly. If unsure of how to properly install, please seek professional advice.
Meets or exceeds AASHTO M252 and AASHTO M294 Type S

Specification Description
Product Width: 14.75 in.
Special Feature(s): N/A
Product Outer Diameter: 14.75 in.
Operating Temperature Range: N/A
Maximum Operating Pressure: N/A
CountryofOrigin: Made in USA
Product Weight: 64 lb.
Type: HDPE Culvert
Material: High Density Polyethylene
Number of Walls: 1
Part Number: HDPE 1220
Application/Use: Used in driveway and roadway culverts
Product Inner Diameter: 12 in.
Product Length: 20 ft.
Wall Thickness: 2.75 in.
Manufacturer Part Number HDPE 1220
Culvert HDPE 12 in. x 20 ft. Corrugated Pipe, HDPE 1220 is rated 4.5 out of 5 by 4.
Rated 5 out of 5 by from As described Bought this to add extra driveway. Arrived in good condition and a timely manner. Store staff helped me order from the online store and I was notified when it shipped and arrived.
Date published: 2019-04-15
Rated 4 out of 5 by from Light weight for easy one man installation The pipe is light enough for one person to maneuver and handle
Date published: 2018-12-13
  • y_2019, m_8, d_5, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_2, tr_2
  • loc_en_US, sid_133085499, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 1ms
  • REVIEWS, PRODUCT

How do you / Can you connect a 10' Culvert HDPE pipe to a 20' pipe to make a 30' length?

Asked by: DSBreeden
Yes-Our HDPE culverts are complete with a bell on one end and a spigot on the other. These are designed to slide together with no tools. As long as the pipes are the same size. The bell end on one pipe, should slide over the spigot end of the other pipe, completing the connection.
Answered by: NRoberts
Date published: 2019-02-21

I may need to cut this at pick up and for use. I see that it is not available here in 10 ft sections. What should I bring to cut it at the time of pick up for transport.

Asked by: DIYroad project
Any type of hand saw typically used for wood will cut the hdpe pipe.
Answered by: NRoberts
Date published: 2018-10-22

How much weight can it handle....if used for an entrance way/ driveway

Asked by: poiu
These culverts are DOT approved, so technically they will support the weight of any DOT approved vehicle when installed correctly. Generally, we would still recommend seeking professional advice when installing if unsure how to properly install.
Answered by: NRoberts
Date published: 2019-02-27

I need to make a slight bend in the pipe to connect two driveway pipes that are at an angel to each other. How much of an angle or can the pipe be bent?

Asked by: wrmcgown
Bending culverts can restrict flow and potentially cause a blockage of debris. Although we do not recommend it, if storm water volume is very a low a slight bend in the pipe should not be an issue.
Answered by: NRoberts
Date published: 2018-10-15

I’m not sure what they are called, but are there ends or finished ends that can be added to these  culverts.

Asked by: Llol
Our HDPE culverts are complete with a bell on one end and a spigot on the other.
Answered by: JasmineH
Date published: 2018-11-14

How deep must these be buried to support DOT vehicles? The details give 0 information and say to ask a professional, yet any professional will need to know the manufacturer specs which are not listed.

Asked by: Stripes
Pipe is DOT approved for a minimum of 1’ of cover and a maximum of 20’ of cover. We do recommend compacting fill material very well with less cover.
Answered by: JWag
Date published: 2019-07-02

can you use these to add in with a already existing metal culvert in place or do they make an adapter

Asked by: benb1983
We would recommend using a like kind product your SKU #133084699 12” Galvanized Culvert 20’ long and SKU # 133085099 Galvanized connecting band.
Answered by: CodyP
Date published: 2019-06-18

If it is cut into 2 10' sections for transport, I can use the bell and spigot to slide back together for installation. Correct??

Asked by: Dave Mtnbiker
Yes, the HDPE pipe can be cut and reconnected using the bell and spigot.
Answered by: JWag
Date published: 2019-07-02
