CountyLine 15 gal. ATV Spot Sprayer, Max 40 PSI, 35 ft. Max Vertical Spray, 25 ft. Max Horizontal Spray
Exclusive
CountyLine 15 gal. ATV Spot Sprayer, Max 40 PSI, 35 ft. Max Vertical Spray, 25 ft. Max Horizontal Spray
Item # 160993799
$79.99
Neighbor’s Club Members earn points with purchases.
Exclusive
CountyLine 15 gal. ATV Spot Sprayer, Max 40 PSI, 35 ft. Max Vertical Spray, 25 ft. Max Horizontal Spray
Item # 160993799
$79.99
New Cardmembers earn a $20 Reward‡ with qualifying purchase of $20 or more plus earn 5% in Rewards+ on this purchase. Valid through 8/9/26.
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
The CountyLine 15 gal. ATV Spot Sprayer has been easily configured to mount to your standard ATV, UTV or lawn tractor. The CountyLine utility sprayer has a 15-gal. heavy-duty, translucent, chemical-resistant tank with a 6-in. wide opening for easy filling and mixing. Featuring a 1 GPM, 12V diaphragm pump, the agriculture sprayer has a maximum pressure of 40 PSI that delivers a 35-ft. maximum vertical spray and a 25-ft. maximum horizontal spray. A double filtration system extends the life of the lawn tractor spot sprayer.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Mount this versatile agriculture sprayer to your standard ATV, UTV or lawn tractor
- 1 GPM, 12V diaphragm pump that provides and exceptional pressure and spray
- CountyLine utility sprayer includes a 15 ft. reinforced hose
- 15-gal. translucent tank of this lawn tractor spot sprayer is heavy-duty and chemical-resistant for durability
- 6 in. wide tank opening allows for easy filling and mixing
- Double filtration system of this extends the life of the UTV spot sprayer
- Maximum PSI: 40
- Maximum spray length: 35 ft. (vertical), 25 ft. (horizontal)
- CountyLine sprayer is backed by a 1-year limited warranty
| Brand | CountyLine |
|---|---|
| Country of Origin | Made in USA |
| Boom Maximum Spray Width | 50 ft |
| Boom Nozzle Count | 1 |
| Chemical Compatibility | Fertilizer |
| Features | 15 gal. CountyLine ATV Spot Sprayer, Max 40 PSI, 35 ft. Max Vertical Spray, 25 ft. Max Horizontal Spray |
| Hose Diameter | 3/4 in. |
| Hose Length | 15 ft. |
| Maximum Flow Rate | 0.4 GPM |
| Maximum Operating Pressure | 40 PSI |
| Product Height | 34.5 in. |
| Product Length | 16.25 in. |
| Product Weight | 14.5 lb. |
| Product Width | 16.25 in. |
| Tank Capacity | 15 gal. |
| Spray Method | Spot Spraying |
| Tank Material | Plastic |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | 97109 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 78 Questions
Newest questions
Q: Strong enough to reach top of 15 ft peach tree?
a month ago1 Answer
- A: Yes, this sprayer is powerful enough to reach the top of a 15-foot tree. It features a 12V diaphragm pump that delivers a maximum vertical spray of 35 feet and a maximum horizontal spray of 25 feet.a month agoHelpful?
Q: Can I spray Diesel?
5 months ago1 Answer
- A: No, this is used for fertilizers, Never spray flammable, caustic, acidic, chlorine, bleach, petroleum based or other corrosive solutions or heat, pressure, or gas producing chemicals.4 months agoHelpful?
Q: does it have wheels avaible for pulling behind something
8 months ago1 Answer
- A: No, The Chapin 15 gal. CountyLine ATV Spot Sprayer has been easily configured to mount to your standard ATV, UTV or lawn tractor only8 months agoHelpful?
Q: How long of hose is attached to this unit
10 months ago1 Answer
- A: Hose length is 15 ft..10 months agoHelpful?
Q: does it plug into a cigarette lighter socket
11 months ago1 Answer
- A: This unit does have a 12v lead wire but it does not have a socket connection – it uses alligator clips to attach to a 12v battery.11 months agoHelpful?
Q: Can I get a replacement pump for this sprayer?
a year ago1 Answer
- A: Please contact Customer Service at 1-800-444-3140 to better assist you with parts.a year agoHelpful?
Q: Does the boom kit work with this so it’s not a spot sprayer
a year ago1 Answer
- A: No, we would not recommend a boom on this unit.a year agoHelpful?
Q: How many amps does it pull
a year ago1 Answer
- A: The Chapin 97102: “15 gal. Countyline ATV Spot Sprayer” pump pulls around 3 ampsa year agoHelpful?
Q: can i use this sprayer for herbicide?
a year ago1 Answer
- A: Yes it will work for weed killers.a year agoHelpful?
Q: Will a spray bar work with these pacage
a year ago1 Answer
- A: Unfortunately, this model will not accommodate a spray boom.a year agoHelpful?
1 - 10 of 78 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 78 Questions
Newest questions
Q: Strong enough to reach top of 15 ft peach tree?
a month ago1 Answer
- A: Yes, this sprayer is powerful enough to reach the top of a 15-foot tree. It features a 12V diaphragm pump that delivers a maximum vertical spray of 35 feet and a maximum horizontal spray of 25 feet.a month agoHelpful?
Q: Can I spray Diesel?
5 months ago1 Answer
- A: No, this is used for fertilizers, Never spray flammable, caustic, acidic, chlorine, bleach, petroleum based or other corrosive solutions or heat, pressure, or gas producing chemicals.4 months agoHelpful?
Q: does it have wheels avaible for pulling behind something
8 months ago1 Answer
- A: No, The Chapin 15 gal. CountyLine ATV Spot Sprayer has been easily configured to mount to your standard ATV, UTV or lawn tractor only8 months agoHelpful?
Q: How long of hose is attached to this unit
10 months ago1 Answer
- A: Hose length is 15 ft..10 months agoHelpful?
Q: does it plug into a cigarette lighter socket
11 months ago1 Answer
- A: This unit does have a 12v lead wire but it does not have a socket connection – it uses alligator clips to attach to a 12v battery.11 months agoHelpful?
Q: Can I get a replacement pump for this sprayer?
a year ago1 Answer
- A: Please contact Customer Service at 1-800-444-3140 to better assist you with parts.a year agoHelpful?
Q: Does the boom kit work with this so it’s not a spot sprayer
a year ago1 Answer
- A: No, we would not recommend a boom on this unit.a year agoHelpful?
Q: How many amps does it pull
a year ago1 Answer
- A: The Chapin 97102: “15 gal. Countyline ATV Spot Sprayer” pump pulls around 3 ampsa year agoHelpful?
Q: can i use this sprayer for herbicide?
a year ago1 Answer
- A: Yes it will work for weed killers.a year agoHelpful?
Q: Will a spray bar work with these pacage
a year ago1 Answer
- A: Unfortunately, this model will not accommodate a spray boom.a year agoHelpful?
1 - 10 of 78 Questions
Similar Items
-
-
-
-
-
-
-
-
-
-
Top Rated
-
-
Reviews
- quality
- purchase
- price
- returns
- satisfaction
- ease of use
- warranty
- setup
1 to 4 of 257 Reviews .
1 – 4 of 257 Reviews
Most Recent
Michigan
Review 1
1 out of 5 stars.
Poor quality parts
2 months ago
Sprayer worked great for first 2 uses. Third time I tried to use it, the nozzle tip cracked and there was leaking from the plastic wand as soon as the pump was powered on.
No, I do not recommend this product.
Missouri
Review 1
1 out of 5 stars.
Bad handle/trigger spray
2 months ago
I had the same problem as others have mentioned with the handle leaking. It worked great for one season. Next season filled it up and went to use it and herbicide mixture squirted out around the handle/trigger all over me. To make it worse, tractor supply didn't even carry a replacement for me to purchase. Leaving me with a full mix ready to spray my fence line and no way to spray for a few days.
No, I do not recommend this product.
Review 1
5 out of 5 stars.
Great for the price point.
10 months ago
Have been able to put a couple of hours use on it so far and seems to be an adequate sprayer for the price paid. I tightened all fittings before the first use and have had no issues with leaks as others have stated. Would recommend for a light duty sprayer based on my experience with it.
Yes, I recommend this product.
Bloomfield, Indiana
Review 1
1 out of 5 stars.
Did Not Last
a year ago
After one season of use, the pump runs but, does not build up pressure
No, I do not recommend this product.
