Carry-On Trailer 2-Leaf Eye to Slipper Spring, 1,000 lb. Max. Capacity
Carry-On Trailer 2-Leaf Eye to Slipper Spring, 1,000 lb. Max. Capacity
Item # 175022699
$54.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
Carry-On Trailer 2-Leaf Eye to Slipper Spring, 1,000 lb. Max. Capacity
Item # 175022699
$54.99
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
The Carry-On Trailer 2-Leaf Eye to Slipper Spring delivers long life and a smooth ride for your cargo. The eye to slipper spring has a 1,000 lb. maximum capacity. The mounting holes in the 2-leaf eye to slipper spring have a 9/16 in. diameter and are 24.25 in. apart. The width of the eye to slipper spring is 1-3/4 in.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Eye to slipper design
- 2-leaf design
- Width of eye to slipper spring: 1-3/4 in.
- 24.25 in. from mounting centers on the eye to slipper spring
- Mounting hole diameter in 2-leaf eye to slipper spring: 9/16 in.
- 1,000 lb. maximum capacity per 2-leaf eye to slipper spring
| Brand | Carry-On Trailer |
|---|---|
| Country of Origin | Imported |
| Axle Capacity | 1,000 lb. |
| Center Of Spring Eye to Center Of Spring Eye Length | 24.25 in. |
| Compatibility | Trailers |
| End Type | Other |
| Leaf Thickness | 1.75 in. |
| Maximum Weight Capacity | 1,000 lb. |
| Mounting Hole Inner Diameter | 9/16 in. |
| Number Of Leaves | 2 |
| Package Quantity | 1 |
| Primary Material | Steel |
| Product Height | 24.25 in. Eye -To -Slipper Length |
| Product Length | 24-1/4 in. |
| Product Weight | 7 lb. |
| Product Width | 1-3/4 in. |
| Spring Capacity Per Pair | 2,000 lb. |
| Manufacturer Part Number | 351T |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 2 of 2 Questions
Newest questions
Q: The product information indicates 24.25" to centers but also indicates 24.25" overall. Is the spring 24.25" overall, center of hanger to center of slipper mount, center of hanger to start of slipper hanger (ideal for my need), or something else?
5 years ago1 Answer
- A: Thank you for your question! The overall size is 24.25"5 years agoHelpful?
Q: Does these come in pairs or single
5 years ago2 Answers
- A: I purchased a single piece. They may also be sold in pairs. But that was not my experience.5 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 2 of 2 Questions
Newest questions
Q: The product information indicates 24.25" to centers but also indicates 24.25" overall. Is the spring 24.25" overall, center of hanger to center of slipper mount, center of hanger to start of slipper hanger (ideal for my need), or something else?
5 years ago1 Answer
- A: Thank you for your question! The overall size is 24.25"5 years agoHelpful?
Q: Does these come in pairs or single
5 years ago2 Answers
- A: I purchased a single piece. They may also be sold in pairs. But that was not my experience.5 years agoHelpful?
Similar Items
-
-
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
-
Items You May Like
-
-
-
Top Rated
-
-
-
-
-
-
-
-
-
Customers Also Bought
-
-
-
Top Rated
-
-
-
-
-
-
-
Top Rated
-
-
Reviews
- installation
- instructions
- price
- purchase
- setup
- weight
1 to 4 of 18 Reviews .
1 – 4 of 18 Reviews
Most Recent
Review 1
5 out of 5 stars.
Excellent fit!
5 days ago
These "two leaf" springs are actually an upgrade over normal. They are 1/4" thicker at the axle plate junction, because they have a small third sleeper leaf, but most u-bracket-bolts have plenty of extra length to accommodate them. Perfect fit. (PS if you are measuring your current springs, and these seem shorter, it's because your current springs are squashed flat from years of pounding, and are a 1-3" longer than new ones.) Once installed, and under normal load, they are perfect.
Cincinnati
Review 1
4 out of 5 stars.
Leaf spring worked great but was a little higher.
5 months ago
I needed to come to apologize and correct my review. I thought the product was assembled wrong until I ordered another set from a different supplier. I then realized that it was assembled correctly, and my trailer was altered prior to my ownership. So my personal trailer was "lifted" to have more ground clearance and the lift springs were modified to work with the axle re-positioning.
In addition, the lift spring purchased from Tractor Supply was heavier than the lift springs purchased from a different supplier. The Tractor Supply lift spring was almost the same exact weight was the lift spring on the trailer. The lift spring that I purchased from a different supplier was almost 30% lighter weight. Does that mean it's weaker? I have no idea, but I do plan to purchase another Tractor Supply lift spring to have a mating pair.
The Tractor Supply lift spring gave the trailer a little more height on the side it was installed on. So I suggest you purchase a pair if you are not dealing with an emergency as I was.
----------------------------------------------------------------------------------------------------------------------------------
Got me off the side of the road, however, it was assembled wrong and has caused several people issues. There is a bold / guide pin installed to hold the leafs together and also is the axle/wheel alignment post. It was installed upside down and the bolt will not go in the hole in the axle. I was able to remove it and flip in allowing me to install it. I posted a YouTube video showing the issue. https://youtu.be/f67kstsEI04
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
6 months ago
Carry-On Trailer Customer Service
Thank you for this information. I will report it to our Parts Department and have them check this 2 Leaf eye to slipper leaf spring to make sure there are not anymore in our system with this problem. I apologize for your inconveince dealing with this issue.
Review 1
5 out of 5 stars.
Great Service and Fast!!
9 months ago
i was really glad at how fast everything went
SweepstakesYes
Yes, I recommend this product.
Response from Carry-On Trailer Customer Service:
9 months ago
Carry-On Trailer Customer Service
Thanks for your kind words and high rating. We are committed to delivering durable, dependable trailer parts.
Anonymous
Las Vegas, Nv.
Review 1
1 out of 5 stars.
Where's Waldo?
2 years ago
It would be nice if after two weeks going on 3, that I would have them to review. First order delivered to Moon I guess, the next one is on the slow boat from China
SweepstakesYes
No, I do not recommend this product.
