Star Water Systems 1/3 HP 115V Electric Cast Iron Submersible Sump Pump with Vertical Switch, 2,880 GPH
Item # 229877199
Neighbor’s Club Members earn points with purchases.
Item # 229877199
This item is available online only
Delivery to
37027
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The Star Water Systems 1/3 HP Cast Iron Sump Pump is the standard for quality and performance. This pump is designed with epoxy coated cast iron construction, stainless steel components, premium vertical switch, and non-clogging vortex impeller capable of passing 1/2 in. spherical solids. This pump is made in the USA using a majority of US content and every pump is 100% water tested before shipment to ensure reliable operation. It's rated for 2,880 GPH.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
Looking for more information on sump pumps? Check out our guide on how to replace a sump pump float switch in the product documents section.
- Cast iron construction for long life and quiet operation
- Corrosion-resistant, powder coated epoxy finish
- Non-clogging vortex impeller passes 1/2 in. solids
- Solid, buoyant float material and stainless steel float switch arm ensure long term reliability
- 1-1/2 in. NPT discharge
- Thermal overload protection keeps motor from overheating
- 100% water-tested before shipment for reliable operation
- Made in the USA using a majority of US content
- 3-year limited warranty
| Brand | Star Water Systems |
|---|---|
| Country of Origin | Made in USA |
| Amperage | 9.7 Amp |
| Basin Diameter | 18 in. |
| Body Material | Cast iron |
| Compatible Pipe Material | PVC |
| Discharge Connection | Threaded Female |
| Discharge Port Diameter | 1.5 in. |
| Discharge Rate at 0 ft. | 2,880 GPH |
| Discharge Rate at 10 ft. | 2,040 GPH |
| Engine Displacement | 0 N/A |
| Features | Epoxy coated cast iron construction, 115V 3/10 HP motor, premium vertical switch, non-clogging vortex impeller capable of passing 1/2 in. solids, thermal overload protection, 100% water tested, Made in the USA using a majority of US content. |
| Horsepower | 0.33 HP |
| Hose Diameter | 1.5 in. |
| Inlet Connection | None |
| Inlet Diameter | 0 N/A |
| Maximum Flow Rate | 2,880 GPH |
| Maximum Head Lift | 18 ft. |
| Maximum Operating Pressure | 8 PSI |
| Maximum Operating Temperature | 130 deg. F |
| Maximum Solids Diameter | 0.5 in. |
| Maximum Suction Lift | 18 ft. |
| Minimum Operating Pressure | 0 N/A |
| Minimum Operating Temperature | 34 deg. F |
| Power Type | Electric |
| Product Height | 10.5 in. |
| Product Length | 10.5 in. |
| Product Weight | 22.4 lb. |
| Product Width | 8 in. |
| Pump Mechanism | Centrifugal |
| Motor Type | 115V Oil Filled |
| Switch-Off Height | 3 in. |
| Switch-On Height | 7.25 in. |
| Voltage | 115v |
| Warranty | 3 Year Limited Warranty |
| Manufacturer Part Number | 3SEHL |
