Piusi USA 0.67 HP 120V Electric Three25 Fuel Pump Kit, 9 GPM, Auto/Meter/Filter/Coupler
Item # 135527999
Add this item to unlock free delivery!
Neighbor’s Club Members earn points with purchases.
Item # 135527999
Add this item to unlock free delivery!
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The Piusi Three25 DEF 120V Kit is the perfect solution for a DEF IBC tote or mini bulk application. The system is equipped with the SuzzaraBlue heavy-duty industry standard 9GPM DEF transfer pump, an easily transferable side-mount bracket, an automatic metered nozzle, a DEF filter, the PDC coupler, 20 ft. of crimped dispense hose and 1.5 ft of crimped suction hose.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 3D DEF filter helps maintain the quality of the DEF dispensed and extend the life of the catalyst
- DEF transfer pump system with a stainless steel bracket and roll bar protection
- Piusi DEF coupler (PDC)
- Security lock bracket system for safe use of the DEF transfer pump system
- High capacity hose holder for extra winding space
- 20 ft. crimped EPDM delivery hose and 6.5 ft. suction hose offer a SEC connection
- SB325 meter automatic nozzle with break-away system with replacement stainless steel spout
- SuzzaraBlue diaphragm transfer pump delivers optimal performance
- cCSAus-certified membrane pump
- 6.5 minute safety shut-off timer
| Brand | Piusi USA |
|---|---|
| Country of Origin | Imported |
| AC or DC Powered | AC |
| Amperage | 4.7A |
| Body Materials | Polypropelyne |
| Compatible Fluids | Diesel Exhaust Fluid |
| Discharge Connection | Threaded Male |
| Discharge Diameter | 1 in. BSP |
| Duty Cycle | 30 min. on/off |
| Features | 6.5 minute timer board, metered nozzle with break-away replacement spout, 3D DEF filter |
| Horsepower | 0.67 HP |
| Hose Diameter | 0.75 in. |
| Inlet Connection | Threaded Male |
| Inlet Diameter | 1 in. BSP |
| Intended Use Grade | Commercial |
| Maximum Flow Rate | 9 GPM |
| Maximum Head Lift | 6.5 ft. |
| Maximum Operating Pressure | 26PSI |
| Maximum Operating Temperature | 110 deg. F |
| Minimum Operating Pressure | 12 deg. F |
| Minimum Operating Temperature | 1 PSI |
| Power Cord Length | 6 ft. |
| Power Type | Electric |
| Product Height | 16 in. |
| Product Length | 15 in. |
| Product Weight | 34 lb. |
| Product Width | 18 in. |
| Voltage | 120V |
| Warranty | 2 Year |
| Manufacturer Part Number | F00101A0A |
