Weekly AdWhat's NewTractor Supply AppEarn Rewards with Neighbor's ClubHometown HeroesLife Out Here BlogTSC Exclusive BrandsTop BrandsClearance ItemsBattery FinderOutdoor Power Equipment Parts FinderHitch FinderPacer Manual Poly Piston Hand Pump for Agriculture Chemicals
Item # 209502799
Neighbor’s Club Members earn points with purchases.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
The HPN series is a hand operated piston pump that helps eliminate dumping and pouring of solutions. This pump can handle low to medium volumes of water, oils, lubricants and mild chemicals, with viscosity capabilities up to 2,000 SSU. It features a two-position pump handle which can help control the discharge and it has a self-lubricating piston ring. The Pacer Pumps HPN 1A hand drum pump includes everything you'll need to move liquids into and out of heavy drums and barrels, including the pump body, assorted valves and valve seals, an O-ring and piston ring, the pump's handle, an 8-foot discharge hose and a polyester suction tube. It is engineered from durable thermoplastics and can be used in a wide range of applications. Please refer to chemical compatibility chart and always refer to the chemicals MSDS sheets before selecting a pump. If you have chemical compatibility or application questions, please contact the sales/technical support team at Pacer Pumps. 1-year Limited manufacturer warranty
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Double acting, Hand operated piston pump
- Engineered from Durable Thermoplastics
- Viscosities up to 2000 SSU
- Two position pump handle
- Self-lubricating piston ring - Operates wet or dry for long life
- Barrel Bung adapter included
- Refer to Chemical Compatibility for the best fit
- Controlled Discharge Rate - 1 qt on every complete forward & backward cycle
- Internal suction screen
- Polyester Pump Body
- Viton O-rings
- Cork Nitrile Gasket
- Discharge Hose - 8' EPDM w/ Polyester elbow & Nozzle
- Suction Tube - 2 Piece 1" Polyester, 34" long with Polyester coupling
- Molded & Assembled in the USA (Lancaster, PA)
| Brand | Pacer |
|---|---|
| Country of Origin | Made in USA |
| Body Material | Polyester |
| Compatible Pipe Material | Plastic |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1 in. |
| Discharge Rate at 0 ft. | 0 gpm |
| Discharge Rate at 10 ft. | 0 ft. |
| Engine Displacement | 0 cc |
| Features | Double acting hand operated piston pump, Viscosities up to 2000 SSU, Self-lubricating piston ring, Engineered durable thermoplastics, Includes suction tube and discharge hose |
| Hose Diameter | 1 in. |
| Inlet Connection | Threaded Female |
| Inlet Diameter | 1 in. |
| Maximum Flow Rate | N/A |
| Maximum Head Lift | 15 ft. |
| Maximum Operating Pressure | 10 PSI |
| Maximum Operating Temperature | 70 deg. F |
| Maximum Suction Lift | 15 ft. |
| Minimum Operating Pressure | 0 PSI |
| Minimum Operating Temperature | 40 deg. F |
| Power Type | None |
| Product Height | 9 in. |
| Product Length | 21 in. |
| Product Weight | 10 lb. |
| Product Width | 9 in. |
| Pump Mechanism | Diaphragm |
| Motor Type | Hand Operated |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | P-59-0002-1A |
