MaxxAirHeavy-Duty Exhaust Fan with Integrated Shutter, 14 in. Blade

SKU # 324061799
Product price

Save Up To
See Price in Store
Why?
Product Rating is 4.0
4.0
(7)
Write a review

Financing Available! Click here for more details...

Quantity

Delivery Options:

Protect Your Purchase

We'll fix it, replace it, or reimburse you for it. Learn More

power plus

Item Information

The MaxxAir Heavy-Duty Exhaust Fan with Integrated Shutter is well suited to ventilate many types of substances from dust to humidity, excluding hazardous chemicals or fumes. For use in Barns, Greenhouses or a variety of other locations.

  • Thermally protected 2.65 A enclosed PSC motor
  • 1,400 CFM, single speed
  • 20 ga. galvanized steel housing
  • Pre-drilled holes for easy installation
  • 28 ga. galvanized gravity operated shutters
  • Requires minimum 4 sq. ft. intake ventilation area (NFA)
  • 1 year limited warranty

Specification Description
Product Type: Exhaust Fans
Power Type: Electric
Stand Type: Wall Mount
Overall Length: 18 in.
Number of Speeds: 1
Brand: MaxxAir
Overall Width: 13 in.
Air Flow: 1,400 CFM
Case Material: Galvanized Steel
Warranty: 1-Year Limited
Fan Blade Diameter: 14 in.
Overall Height: 18 in.
Manufacturer Part Number IF14
MaxxAirHeavy-Duty Exhaust Fan with Integrated Shutter, 14 in. Blade is rated 4.0 out of 5 by 7.
Rated 2 out of 5 by from Not 14" The fan is actually less than 14" and the fan housing is greater than 15". The box opening is listed nicely on the website, but you may need to know what size the circular fan housing actually is for those DIY individuals. If you are going to cut a square in a wall and mount the fan and be done, you have all the required info. If you need to cut a circle that the fan housing penetrates through, then cut a 15.5-16" hole. There is actually nothing on this product that measures 14"... not the depth, the fan, or the housing.
Date published: 2017-12-18
Rated 5 out of 5 by from Perfect for my hatching barn. I bought this to create a negative pressure area in the barn for hatching and brooding chicks. Medium speed keeps the air flowing out of the barn, as well as all the fine dust from newly hatched chicks. This keeps the debris from collecting on all the farm equipment. Perfect and powerful.
Date published: 2017-08-21
Rated 5 out of 5 by from Quality fan installed fan in a corrugated metal building , the mounting flanges made it a easy hassle free install. added a thermostat making it automatic. helps cool and keep the building dry.
Date published: 2015-12-25
Rated 5 out of 5 by from This fan is AWESOME. .....I needed to clear MIG welding fumes out of a 2.5 car garage. I fit this fan up at the top of the wall at the ceiling apex and it clears all smoke out of the building effectively. Highly recommended!
Date published: 2011-05-25
  • y_2018, m_7, d_20, h_19
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_7
  • loc_en_US, sid_324061799, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 5ms
  • REVIEWS, PRODUCT

Is this product OSHA approved?

Asked by: Duckymj
This fan has 2 OSHA-compliant features including a safety grille and a fully enclosed, thermally protected, PSC energy efficient motor.
Answered by: CustomerService
Date published: 2017-06-20

does this fan have a db rating? how loud is it?

Asked by: joe fan man
Hi joe fan man, Unfortunately, we do not have any tested values available for db ratings associated with this model.
Answered by: CustomerService
Date published: 2017-03-27

Can this fan be used to remove paint fumes? Specifically Automotive industry clear and base coats?

Asked by: Ltp49770
Hello Ltp49770, Unfortunately, this fan unit is not suitable for exhausing hazardous chemicals or fumes.
Answered by: CustomerService
Date published: 2017-01-27

Is this fan thermostatic controlled or do I have to buy one?

Asked by: Tracker1
Hello Tracker1, our exhaust fans do not come with a thermostat. If you need a thermostat our Adjustable Thermostat with Firestat (Model #XXFIRESTAT) can be used with our exhaust fans. For more information please contact our customer service department at 1-800-433-1626 and we will be happy to assist you.
Answered by: CustomerService
Date published: 2018-06-05

what is the rpm of this motor?

Asked by: bbapple
Hi bbapple, This unit operates at 1130 RPM.
Answered by: CustomerService
Date published: 2016-10-06

What is the motor size, voltage and amperage?

Asked by: mike 2
Hi mike 2, This unit uses a NEMA 42-frame motor and operates using 120V / 2.65 Amps.
Answered by: CustomerService
Date published: 2016-08-16

What is this width of the housing? (What size hole is needed?) Says 14 inch blade but specs say 13in?

Asked by: toddjude
Hi toddjude, This unit will require a rough opening of 17.25" x 17.25".
Answered by: CustomerService
Date published: 2017-08-03

Is there a cover made for the side of the fan thats on the in doors? I am Having a house built with an attached shop. The electrician has installed the fan but for safety I need a cover on the inside.

Asked by: Dave73
There should be a finger guard, or grille, on the indoor side of the fan that will prevent anything from coming in contact with the blade. If your unit is missing this grille please contact our customer service department at (800) 433-1626
Answered by: CustomerService
Date published: 2018-06-04
