Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up

Shop all Magpul
Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up

Item # 6123608

Magpul Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up
Magpul Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up
$55.99
Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up

Item # 6123608

Magpul Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up
Magpul Magpul MBUS Rear Sight for AR-15/ M16, Olive Drab Green, Polymer, Spring-Loaded Flip Up
$55.99

The MBUS (Magpul Back-Up Sight) is a low-cost, color injection molded, folding back-up sight. The dual aperture MBUS Rear Sight is adjustable for windage and fits most 1913 Picatinny rail equipped weapons, but is specifically tailored to the AR15/M16 platform. Spring-loaded flip up sight easily activated from either side or by pressing the top release. Protective wings shield the dual, same plane flip apertures. Sight can still be folded with either large or small aperture in position. Detent knob easily and positively adjusts windage. 0.7 MOA (0.754"/100m) per click with a 14.5" sight radius. 0.5 MOA (0.547"/100m) per click with a 20" sight radius. Cannot be mounted to a railed gas block due to excess heat issues. Front MBUS must be mounted to a railed fore end on the same plane as the receiver rail. Because of this the sight is also not compatible with MOE Hand Guards. Made in the USA.

  • MBUS (Magpul Back-Up Sight) is a low-cost, color injection molded, folding back-up sight
  • Dual aperture MBUS rear sight is adjustable for windage
  • Fits most 1913 Picatinny rail-equipped weapons, but is specifically tailored to the AR15/M16 platform
  • Spring-loaded flip-up design is easily activated from either side or by pressing the top release
  • Protective wings shield the dual, same-plane flip apertures
  • Sight can still be folded with either large or small aperture in position
  • Detent knob provides easy, positive windage adjustment
  • Windage adjustment click values: 0.7 MOA (0.754"/100m) per click with 14.5" sight radius
  • Windage adjustment click values: 0.5 MOA (0.547"/100m) per click with 20" sight radius
  • Cannot be mounted to a railed gas block due to excess heat issues
  • Front MBUS must be mounted to a railed fore end on the same plane as the receiver rail
  • Not compatible with MOE Hand Guards
  • Made in the USA
  • Firearm Fitment: AR-15
  • Color: Olive Drab Green
  • Firearm Type: AR Platform
  • Frame Material: Polymer
  • Mount Type: Picatinny Rail/STANAG 4694 Rail
  • Style: Folding Back Up Sight
  • Weight: 1.30 oz
  • Windage Adjustment: 50 MOA
