CountyLine Adjustable Category 1 Top Link, Extra Long
$64.99
CountyLine Adjustable Category 1 Top Link, Extra Long
CountyLine Adjustable Category 1 Top Link, Extra Long
Item # 267725
$64.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
$64.99
New Cardmembers earn a $20 Reward‡ with qualifying purchase of $20 or more plus earn 5% in Rewards+ on this purchase. Valid through 6/28/26.
Shopping at
Grassland (franklin) TN
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
For a secure setup, use the CountyLine Adjustable Category 1 Top Link. Durably made, this top link pin is a reliable option for category 1 tractors. The pin boasts an extra-long length for added utility. 1-1/8 in. NC threads.
- Extra-long category 1 top link pin
- For use with compatible tractor hitches
- Size of the top link pin: 1-1/8 in. NC threads; 20 in. L; 3/4 in. ball sockets
- Made in India
- 1-year limited warranty
| Brand | CountyLine |
|---|---|
| Country of Origin | Imported |
| Compatibility | Compact tractors |
| Hitch Type | Category 1 |
| Package Quantity | 1 |
| Primary Color | Yellow |
| Primary Material | Other |
| Product Height | 1.77 in. |
| Product Length | 32 in. |
| Product Weight | 9 lb. |
| Product Width | 2.20 in. |
| Warranty | 1 Year Limited |
| Manufacturer Part Number | 11STL022TSC |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 14 Questions
Newest questions
Q: What is the thickness of the rod ends from the two faces of the ball joint? If I want to interface the rod end into a clevis or slot, I need to know the thickness. Also, is 32" the max length? What is the usable range of length?
4 months ago1 Answer
- A: The CAT 1 Extra long top link the maximum open length is 35” and the closed length is 25” with 10 inches of useable length. The bore length, or the thickness of the ball joint is 1-5/8”.4 months agoHelpful?
Q: Which stabilizer part do I need for my 4440 jd
8 months ago1 Answer
- A: This one is not a simple one. The JD 4440 can be set to use a CAT1, CAT2 or CAT3, 3 point. So, this one will depend upon the pin size the tractor has for the top link. However, they can use a bushing to reduce the hole size on the tractor down to CAT 1 or CAT 2 size. The County Line extra long top link will work, but they may need to create a bushing to go from CAT 3 to CAT1. Or use County Line CAT ½ top link and use a CAT 3/2 bushing.8 months agoHelpful?
Q: What is the fully extended length?
a year ago1 Answer
- A: The extra long top link should have a maximum length of about 35”. If it is adjusted past this point the end will become unscrewed from link.a year agoHelpful?
Q: How do I know if I have reached the maximum extension. Does it have a stop to keep from totally unscrewing?
a year ago1 Answer
- A: The extra long top link should have a maximum length of about 35”. If it is adjusted past this point the end will become unscrewed from link.a year agoHelpful?
Q: Will this work on a ford 2n tractor
2 years ago1 Answer
- A: The County Line post hole digger should have no issues with the Ford 2N.2 years agoHelpful?
Q: Will this fit a 1981 John Deere 2440?
3 years ago1 Answer
- A: The County Line CAT1 Extra long top link will fit the John Deere 2440. The part of this question that I can’t answer is if this customer implements need the extra 4” of length that the extra-long top link provides.3 years agoHelpful?
Q: WHAT IS THE CENTER TO CENTER MINIMUM
5 years ago2 Answers
- A: Please contact Customer Service at (888) 376-9601 available Monday-Friday 8am-8pm (EST), Saturday 8am-5pm (EST), so we can better assist you.5 years agoHelpful?
Q: How strong are these?
5 years ago3 Answers
- A: Please contact Customer Service at (888) 376-9601 available Monday-Friday 8am-8pm (EST), Saturday 8am-5pm (EST), so we can better assist you5 years agoHelpful?
Q: Will this extended top link allow an attachment to lower closer to the ground? I need to lower a subsoiler closer to the ground. Better solution?
5 years ago2 Answers
- A: Your lift arms determine how low. A top link controls the angle.5 years agoHelpful?
Q: What is the center to center at max
5 years ago2 Answers
- A: 35".5 years agoHelpful?
1 - 10 of 14 Questions
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 14 Questions
Newest questions
Q: What is the thickness of the rod ends from the two faces of the ball joint? If I want to interface the rod end into a clevis or slot, I need to know the thickness. Also, is 32" the max length? What is the usable range of length?
4 months ago1 Answer
- A: The CAT 1 Extra long top link the maximum open length is 35” and the closed length is 25” with 10 inches of useable length. The bore length, or the thickness of the ball joint is 1-5/8”.4 months agoHelpful?
Q: Which stabilizer part do I need for my 4440 jd
8 months ago1 Answer
- A: This one is not a simple one. The JD 4440 can be set to use a CAT1, CAT2 or CAT3, 3 point. So, this one will depend upon the pin size the tractor has for the top link. However, they can use a bushing to reduce the hole size on the tractor down to CAT 1 or CAT 2 size. The County Line extra long top link will work, but they may need to create a bushing to go from CAT 3 to CAT1. Or use County Line CAT ½ top link and use a CAT 3/2 bushing.8 months agoHelpful?
Q: What is the fully extended length?
a year ago1 Answer
- A: The extra long top link should have a maximum length of about 35”. If it is adjusted past this point the end will become unscrewed from link.a year agoHelpful?
Q: How do I know if I have reached the maximum extension. Does it have a stop to keep from totally unscrewing?
a year ago1 Answer
- A: The extra long top link should have a maximum length of about 35”. If it is adjusted past this point the end will become unscrewed from link.a year agoHelpful?
Q: Will this work on a ford 2n tractor
2 years ago1 Answer
- A: The County Line post hole digger should have no issues with the Ford 2N.2 years agoHelpful?
Q: Will this fit a 1981 John Deere 2440?
3 years ago1 Answer
- A: The County Line CAT1 Extra long top link will fit the John Deere 2440. The part of this question that I can’t answer is if this customer implements need the extra 4” of length that the extra-long top link provides.3 years agoHelpful?
Q: WHAT IS THE CENTER TO CENTER MINIMUM
5 years ago2 Answers
- A: Please contact Customer Service at (888) 376-9601 available Monday-Friday 8am-8pm (EST), Saturday 8am-5pm (EST), so we can better assist you.5 years agoHelpful?
Q: How strong are these?
5 years ago3 Answers
- A: Please contact Customer Service at (888) 376-9601 available Monday-Friday 8am-8pm (EST), Saturday 8am-5pm (EST), so we can better assist you5 years agoHelpful?
Q: Will this extended top link allow an attachment to lower closer to the ground? I need to lower a subsoiler closer to the ground. Better solution?
5 years ago2 Answers
- A: Your lift arms determine how low. A top link controls the angle.5 years agoHelpful?
Q: What is the center to center at max
5 years ago2 Answers
- A: 35".5 years agoHelpful?
1 - 10 of 14 Questions
Similar Items
-
-
Top Rated
-
-
-
-
-
-
Top Rated
-
-
-
Top Rated
-
Top Rated
Items You May Like
-
-
-
Top Rated
-
-
-
-
-
-
-
-
Top Rated
-
Customers Also Bought
-
-
-
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Reviews
- purchase
- adjustability
- installation
- maneuvering
- quality
- size
1 to 4 of 27 Reviews .
1 – 4 of 27 Reviews
Most Recent
Royersford, PA
Review 1
5 out of 5 stars.
Perfect fit
a month ago
Perfect fit for attaching a single-bottom plow to tractor.
Yes, I recommend this product.
Anonymous
Missouri
Review 1
5 out of 5 stars.
Expectations met.
11 months ago
Link was as strong as the one I was replacing and worked well.
SweepstakesYes
Yes, I recommend this product.
Review 1
5 out of 5 stars.
Exactly what we needed.
a year ago
Easy same day delivery was a life saver on this one. Great product for our Kubota.
SweepstakesYes
Yes, I recommend this product.
Review 1
1 out of 5 stars.
Poor description
3 years ago
Product description is worthless. Doesn't tell ball socket size, overall length, working length??
