Hopkins Towing Solutions 6 in. 12V Sealed Oval Stop/Tail/Turn Light
Hopkins Towing Solutions 6 in. 12V Sealed Oval Stop/Tail/Turn Light
Item # 16543699
$13.99
Neighbor’s Club Members earn points with purchases.
Hopkins Towing Solutions 6 in. 12V Sealed Oval Stop/Tail/Turn Light
Item # 16543699
$13.99
Out of stock at or near
Grassland (franklin) TN
Out of stock delivering to
37027
This item is not available
Search Stores
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
The sealed 6" oval stop/tail/turn light in red is designed to conform to applicable U.S. FMVSS108 and Canadian CMVSS safety standards. The tough polycarbonate lens and resin housing are hermetically sealed to prevent water intrusion and corrosion, ensuring long life of the light. The light can be installed on trailers over and under 80 In. wide and can be mounted either horizontally or vertically. Includes rubber grommet and 3-prong wire for quick and easy installation.
- Works with 12 V systems
- Vertical or horizontal mounting position
- Grommet mount installation
- Lens and housing are hermetically sealed to prevent water intrusion for long life
- Current draw: 3.0 Amps
| Brand | Hopkins Towing Solutions |
|---|---|
| Country of Origin | Imported |
| Bulb Type | LED |
| Compatibility | 12 V systems |
| Features | Lens and housing are hermetically sealed to prevent water intrusion for long life |
| Light Color | Red |
| Mounting Location | Trailer |
| Mounting Type | Grommet |
| Number of Connections | 3 |
| Package Quantity | 1 |
| Power Type | 12 Volt |
| Primary Material | Polycarbonate |
| Product Height | 6-1/2 in. |
| Product Length | 2-3/8 in. |
| Product Weight | 2.3 lb. |
| Product Width | 1/2 in. |
| Shape | Oval |
| Voltage | 12 V |
| Warranty | Hopkins Manufacturing Corporation warrants this product to be free from defects in material and workmanship, under normal use and service, for the original buyer, for a period of 90 days from the date of original purchase. |
| Wattage | 36 W |
| Wire Length | 6 in. |
| Manufacturer Part Number | T85BR |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: Does this tail light vome with all the wiring to hook up
a year ago1 Answer
- A: Hello, thank you for your question. It includes rubber grommet and 3-prong wire for quick and easy installation.a year agoHelpful?
Q: are the pigtail plugs included?
a year ago1 Answer
- A: Hi, This set includes the following Includes rubber grommet and 3-prong wire for quick and easy installation. Works with 12 V systems Vertical or horizontal mounting position Grommet mount installation Lens and housing are hermetically sealed to prevent water intrusion for long life Current draw: 3.0 Ampsa year agoHelpful?
Q: Will this fit a 1.25" receiver?
3 years ago1 Answer
- A: Hi there, I'm not sure what you mean, here are the dimensions. Dimensions are 6.5 in. W x 2.25 in. H x 2.38 in. D3 years agoHelpful?
Q: do you have this light in amber
3 years ago1 Answer
- A: Hello, Unfortunately we do not carry this product in amber.3 years agoHelpful?
Q: Any photos of back and wiring? Would like to plan how to attach and hook up. Thx
4 years ago1 Answer
- A: Linked below is an installation video. If you need any further assistance, please call 1-800-835-0129 Monday-Friday, 8-5 central time. https://youtu.be/sB8gR8RqKzo4 years agoHelpful?
Q: Waterproof? For boat trailers?
4 years ago1 Answer
- A: The tough polycarbonate lens and housing are hermetically sealed to prevent water intrusion and corrosion, ensuring long life of the light. This light can be used for boat trailers.4 years agoHelpful?
Q: I bought this kind and was hopping to get them hooked up fast and easy WOW not a chance with only a black and red wire white is a ground They DO NOT HOOK UP to my Boat Trailer with yellow brown red green and white Wire unless you can get me a wire Diagram
7 years ago1 Answer
- A: Handymat46 On the T85BR the red wire is your turn/brake which would go to the green on the passenger side and yellow on the driver side of the trailer. The black wire is the tail marker wire and will go to the brown wire on either side of your trailer. White goes to ground. If you have any more questions please call 1-800-835-0129 Monday-Friday, 8-5 central time. Thanks7 years agoHelpful?
Q: can the light bulbs be changed or do you have to replace entire fixture
7 years ago1 Answer
- A: It is a sealed unit and the bulb is not replaceable.7 years agoHelpful?
Q: Is this a LED light ?
8 years ago1 Answer
- A: This is an incandescent light.8 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 9 of 9 Questions
Newest questions
Q: Does this tail light vome with all the wiring to hook up
a year ago1 Answer
- A: Hello, thank you for your question. It includes rubber grommet and 3-prong wire for quick and easy installation.a year agoHelpful?
Q: are the pigtail plugs included?
a year ago1 Answer
- A: Hi, This set includes the following Includes rubber grommet and 3-prong wire for quick and easy installation. Works with 12 V systems Vertical or horizontal mounting position Grommet mount installation Lens and housing are hermetically sealed to prevent water intrusion for long life Current draw: 3.0 Ampsa year agoHelpful?
Q: Will this fit a 1.25" receiver?
3 years ago1 Answer
- A: Hi there, I'm not sure what you mean, here are the dimensions. Dimensions are 6.5 in. W x 2.25 in. H x 2.38 in. D3 years agoHelpful?
Q: do you have this light in amber
3 years ago1 Answer
- A: Hello, Unfortunately we do not carry this product in amber.3 years agoHelpful?
Q: Any photos of back and wiring? Would like to plan how to attach and hook up. Thx
4 years ago1 Answer
- A: Linked below is an installation video. If you need any further assistance, please call 1-800-835-0129 Monday-Friday, 8-5 central time. https://youtu.be/sB8gR8RqKzo4 years agoHelpful?
Q: Waterproof? For boat trailers?
4 years ago1 Answer
- A: The tough polycarbonate lens and housing are hermetically sealed to prevent water intrusion and corrosion, ensuring long life of the light. This light can be used for boat trailers.4 years agoHelpful?
Q: I bought this kind and was hopping to get them hooked up fast and easy WOW not a chance with only a black and red wire white is a ground They DO NOT HOOK UP to my Boat Trailer with yellow brown red green and white Wire unless you can get me a wire Diagram
7 years ago1 Answer
- A: Handymat46 On the T85BR the red wire is your turn/brake which would go to the green on the passenger side and yellow on the driver side of the trailer. The black wire is the tail marker wire and will go to the brown wire on either side of your trailer. White goes to ground. If you have any more questions please call 1-800-835-0129 Monday-Friday, 8-5 central time. Thanks7 years agoHelpful?
Q: can the light bulbs be changed or do you have to replace entire fixture
7 years ago1 Answer
- A: It is a sealed unit and the bulb is not replaceable.7 years agoHelpful?
Q: Is this a LED light ?
8 years ago1 Answer
- A: This is an incandescent light.8 years agoHelpful?
Similar Items
-
Top Rated
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
Top Rated
-
Top Rated
-
-
Top Rated
-
-
Top Rated
Items You May Like
-
-
-
Top Rated
-
-
-
-
-
-
-
-
-
Customers Also Bought
-
Top Rated
-
Top Rated
-
Top Rated
-
Top Rated
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
-
Top Rated
-
Reviews
- purchase
1 to 2 of 4 Reviews .
1 – 2 of 4 Reviews
Most Recent
Sallisaw ok
Review 1
3 out of 5 stars.
Works great till the bulb goes out
4 months ago
It's been a good set of lights for 8 years but I didn't realize it when I bought it that you can't change the bulb in it. I've been careful not to smash into anything with my tail lights and now I still have to buy a whole new housing. Going with a different style on the next one.
No, I do not recommend this product.
Sturgis mi
Review 1
5 out of 5 stars.
Great exact replacement
3 years ago
Great product exact replacement works good
