Big Red 2 Ton Engine Hoist

SKU: 11674699
Big Red 2 Ton Engine Hoist
Enter Zip Code for price More Info
Product price

Save Up To
See price at checkout More Info
Product Rating is 4.4
4.4
 (99)

Quantity

Check Availability at Other Stores
Standard Delivery Not Available to
Notice: This item will ship within 0 days.
This product may require up to 0 additional days for order processing prior to shipping.
Change Delivery Location

Item Information

  • Lift Height with chain: 93-3/4 in.
  • Lift Height: 89 in.
  • Lifting capacity: 2 Ton
  • Folding design easy to storage
  • including a 8 Ton long ram jack
  • 4-hole position
  • 6-wheels easy move
  • Heavy-duty steel construction
  • 100% factory tested

NOTE: This product ships via over-the-road common carrier truck. Carrier destination shipping charges are included in the order shipping fee that will be displayed in the shopping cart. This product is delivered to the ground level exterior of your home and requires signature upon delivery. For more information, please refer to our Terms & Conditions.

Note: This product may require up to 2 additional days for order processing prior to shipping

Specification Description
Maximum Product Height: 93-3/4 in.
Base Width: 21-3/10 in.
Type: Engine Hoist
Brand: Torin
Capacity: 2 Tons
Minimum Product Height: 6-3/10 in.
Base Length: 59-4/5 in.
Manufacturer Part Number T32001
Big Red 2 Ton Engine Hoist is rated 4.4 out of 5 by 99.
Rated 5 out of 5 by from BIG RED ENGINE HOIST Works great easy to move around and being its foldable for easy storage
Date published: 2020-06-05
Rated 3 out of 5 by from Good....after getting leg pins to align The assembly went fairly well. I just hand tightened the bolts until I got it all together. That is my guess why others had the problem of the support brackets not lining up. After it was all together I tightened everything. The problem I have is when I lower the legs I can’t get the holes for the pins to line up. There is about a 3/4” gap. I placed a1x4x24 board down and rolled the middle wheels onto it. This causes the legs to drop allowing me to insert the pins. I also have to use the board to remove the pins. Other than this problem time will tell if it is sturdy enough.
Date published: 2020-05-11
Rated 5 out of 5 by from Just what I needed Works as advertised. I have used it for several different things now and every time it has worked great. The legs are a bit difficult to pin in place when you lower them to the ground but it’s nothing I can’t live with. All and all good value for the money.
Date published: 2020-05-07
Rated 5 out of 5 by from Awesome engine hoist This is a awesome engine hoist. Fold up and easy storage
Date published: 2020-05-02
  • y_2020, m_8, d_3, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.10
  • cp_1, bvpage1
  • co_hasreviews, tv_25, tr_74
  • loc_en_US, sid_11674699, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • LOCAL, getContent, 4ms
  • REVIEWS, PRODUCT

What is the effective reach?  In other words, the length from the piston shaft to the hook at maximum boom extension. Thanks

Asked by: Dawgfever
The manufacturer provided us with the following information: Length between ram and end of extension: 1/2 ton - 49", 1 ton - 41", 1.5 ton - 34.5", 2 ton - 27.5". Ram fully extended at: 1/2 ton - 81", 1 ton - 76.5", 1.5 ton - 72", 2 ton - 68".
Answered by: NRoberts
Date published: 2019-08-01

How much warranty?

Asked by: Kyle M
We have a 1 year limited parts warranty on our products with proof of purchase
Answered by: Torin Jacks, Inc
Date published: 2016-10-16

Do you have this with air and hydraulic pumps

Asked by: Gschurig
This is a hydraulic pump only.
Answered by: JasmineH
Date published: 2019-03-30

Can this product be used to lift a John Deere 661R riding mower for the purpose of changing blades?

Asked by: Imanol
It COULD be used for that. Instead, we recommend the Pro-Lift 500lb Lawn Mower Lift SKU 1046773.
Answered by: DanielB
Date published: 2017-04-05

what kind of oil goes in the cylinder

Asked by: Bruce VB
Hydraulic Jack Fluid. We recommend SKU # 1106762.
Answered by: NRoberts
Date published: 2019-11-30

What is the maximum reach of the arm? e.g. Can I reach into a 8' bed of a pick up and lift an engine with the tailgate down?f I need to be able to extend the arm to at least 72"

Asked by: GlennM86
Lifting range: 1" - 78-3/4"
Answered by: DanielB
Date published: 2019-09-20

how much does it weigh?

Asked by: Melwood
Approximately 215 lbs.
Answered by: BrittanyH
Date published: 2018-10-20

"How long is the reach?" Daniel keeps saying how high the ram will lift. That is NOT what we are asking. How long is the reach? Look at the picture with me! See that chain with the hook? Need measurement from chain to the ram!

Asked by: ApacheOne
Page three of the manual at the following link was where the manufacturer advised that this information can be found, as the heights and lengths vary depending on where the jib (arm) is extended to. http://www.torinjacksusa.com/images/torinjacks/manual/Bigred/T32001(T32002X).pdf
Answered by: NRoberts
Date published: 2020-04-04
