VIAIR 100C Silver Bare Compressor Kit, No Leader Hose or Check Valve
Item # 138380499
$124.99
Neighbor’s Club Members earn points with purchases.
$124.99
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
The Viair - 100C Silver Compressor Kit comes with a remote mount air filter assembly, rubber isolated mounting feet as well as insulated electric terminals. The maximum working pressure of the silver compressor kit is 130 PSI and the maximum 12V amp draw is 14 amps. The mounting hardware included with the compressor kit allows for easy installation. Two replacement air filter elements are also included in the compressor kit as a backup to keep the system running efficiently.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- 12-volt silver compressor kit
- Duty Cycle: 15% @ 100 PSI
- Max. working pressure of compressor kit: 130 PSI
- No leader hose or check valve
- Max. air tank size of compressor kit: 1.0 gal.
- Max. 12V amp draw: 14 Amps
- Note: Use thread sealant for proper installation. Thread tape is not recommended. Properly sealed, recommended torque is 12 to 15 ft. lb.
- Thermal overload protector
- Vibration isolators
- Mounting hardware included for easy installation
- Air line for remote mount air filter included in silver compressor kit
- Two replacement air filter elements
- Permanent magnetic motor
- Ingress protection rating: IP54
- Dimensions: 6.35 in. L x 3.3 in. W x 4.9 in. H
- Net weight: 3.55 lb.
- Rubber isolated mounting feet and insulated electric terminals included
