Phoenix 2-1/2 in. x 3/4 in. General Purpose V-Groove Drive Pulley for Power Transmission
Phoenix 2-1/2 in. x 3/4 in. General Purpose V-Groove Drive Pulley for Power Transmission
Item # 118503199
Stocked & Ready
$16.99
Get everything you need
Neighbor’s Club Members earn points with purchases.
Phoenix 2-1/2 in. x 3/4 in. General Purpose V-Groove Drive Pulley for Power Transmission
Item # 118503199
Stocked & Ready
$16.99
Shopping at
Grassland (franklin) TN
Delivery to
Pickup Nearby at FRANKLIN TN(6.7) miles Free
Ship to store at Grassland (franklin) TN
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Get everything you need
Neighbor’s Club Members earn points with purchases.
Elevate the performance of your power transmission systems with our robust V-Groove Drive Pulley, a versatile and durable component perfect for a wide range of applications. Tailored for a wide range of power transmission applications including compressors, industrial fans, lawnmowers, snowblowers, and electrical motors. Whether you're maintaining existing equipment or building a new system, our V-Groove Drive Pulley offers the quality, durability, and versatility you need to keep your operations running smoothly.
- Outside Diameter: 2-1/2", Inside Diameter: 3/4", Width: .8", Belts That Fit: 4L/A, Groove Angle: 34 Degrees, Keyway: .188", Material: Steel
- Wide Application Range: Specially designed for general purpose use in power transmission. Ideal for various machines including compressors, industrial fans, lawnmowers, snowblowers, and electrical motors.
- Set Screws: Equipped with 2 set screws, factory inserted to ensure maximum strength and durability.
- Material: Made of heavy-duty steel, stamped construction built to withstand rigorous use in various environments.
- Belt Compatibility: Designed to work efficiently with 4L/A belts, providing a secure and stable operation. Engineered to minimize friction and wear on belts, extending the lifespan of both the belt and the pulley.
- Rust-Resistant Coating: Zinc-coated for superior rust prevention, ensuring long-term resilience and reliability even in harsh conditions.
| Brand | Phoenix |
|---|---|
| Country of Origin | Imported |
| Belt Type | A-Belt |
| Bore Diameter | 0.75 in. |
| Compatibility | General Purpose Pulley for Power Transmission Applications |
| Groove Type | V-groove |
| Maximum Belt Width | 0.5 in. |
| Minimum Belt Width | 0.5 in. |
| Number Of Grooves | 1 |
| Primary Material | Steel |
| Product Diameter | 2.5 in. |
| Product Height | 2.5 in. |
| Product Length | 2.5 in. |
| Product Weight | 0.55 lb. |
| Product Width | 2.5 in. |
| Warranty | TERRE warrants to the original user that any products supplied by TERRE to be free from defects in material and workmanship under normal use or service for a period of one year from the date of purchase. This excludes normal wear and routine maintenance. |
| Manufacturer Part Number | 125034 |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Is the belt size for this 1/2"?
3 years ago1 Answer
- A: Yes, The belt size for that part is ½”.3 years agoHelpful?
Q: My old pulley is a 2 piece 3/4 x 2 1/2” on a craftsman front tine tiller. Will this be as good? Is the key easy to remove when it’s new?
4 years ago1 Answer
- A: Yes, this should be a good replacement.4 years agoHelpful?
Q: What is the size of the keyway?
Anonymous5 years ago1 Answer
- A: 3/16in. standard shaft keyway size5 years agoHelpful?
Q: What size set screw does it use? Mine vibrated out and was lost.
Anonymous7 years ago1 Answer
- A: 5/16- 18 x 5/167 years agoHelpful?
Q: What is the bore diameter of this pulley?
9 years ago1 Answer
- A: The bore diameter is 3/4".9 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Is the belt size for this 1/2"?
3 years ago1 Answer
- A: Yes, The belt size for that part is ½”.3 years agoHelpful?
Q: My old pulley is a 2 piece 3/4 x 2 1/2” on a craftsman front tine tiller. Will this be as good? Is the key easy to remove when it’s new?
4 years ago1 Answer
- A: Yes, this should be a good replacement.4 years agoHelpful?
Q: What is the size of the keyway?
Anonymous5 years ago1 Answer
- A: 3/16in. standard shaft keyway size5 years agoHelpful?
Q: What size set screw does it use? Mine vibrated out and was lost.
Anonymous7 years ago1 Answer
- A: 5/16- 18 x 5/167 years agoHelpful?
Q: What is the bore diameter of this pulley?
9 years ago1 Answer
- A: The bore diameter is 3/4".9 years agoHelpful?
Similar Items
-
Top Rated
-
Top Rated
-
-
-
-
-
Top Rated
-
-
Top Rated
-
-
-
Top Rated
Reviews
- metal
- strong
1 to 1 of 3 Reviews .
1 – 1 of 3 Reviews
Most Recent
Stamford, TX
Reviews 6
5 out of 5 stars.
Awesome
6 years ago
Very good and strong metal, with no imperfections.
Yes, I recommend this product.
