GroundWork Max Coverage Tri-Pod Sprinkler

SKU # 451072299
Enter Zip Code for price
Product price

Save Up To
See price at checkout Why?
Product Rating is 2.3
2.3
(32)
Write a review

Financing Available! Click here for more details...

Quantity

Autoship

Pickup In Store

This item will ship within 0 days.

Delivery Options for

This item will ship within 0 days.

Item Information

Waters Your Lawn Properly

The GroundWork Max Coverage Tri-Pod Sprinkler is designed to hydrate your lawn with efficiency. This fully-adjustable pulsating sprinkler ensures your lawn gets the water needed to stay healthy.

Adjustable Coverage Options

With the GroundWork Max Coverage Tri-Pod Sprinkler you can customize the area you want to spray. Switch between partial and full 360-degree coverage, and adjust the intensity from gentle mist to powerful jet stream.

Durable Rust-Resistant Base

The GroundWork Max coverage Tri-Pod Sprinkler has a rugged tripod base designed for above ground mounting. This rust-resistant tripod is adjustable and stands tall so you can water hard-to-reach spots from up to 105 feet away.

Details:

  • Pulsating sprinkler
  • Adjustable Coverage (up to 360-degree oscillation)
  • Coverage radius: up to 105 ft.
  • Contains diffuser pin to adjust spray intensity
  • Rust-resistant tripod base
  • Size: 3-1/4 in. x 58 in. x 8-3/4 in.

Specification Description
Product Type: Sprinklers
Maximum Spray Radius: 105 ft.
Product Height: 3-1/4 in.
Product Width: 8-3/4 in.
Brand: GroundWork
Product Length: 58 in.
Manufacturer Part Number X1000ZJ-58
GroundWork Max Coverage Tri-Pod Sprinkler is rated 2.3 out of 5 by 32.
Rated 1 out of 5 by from Junk I bought this and turned it on to get it set up where I wanted it. I staked it down and shut the water off. It worked fine. Two weeks later when I finally felt like I should water my pasture, I turned it on and the hose fitting had split where it connects to the sprinkler. I tried fixing it before I retuned it with no luck. These are so flimsy. I probable should have known better just by how light it is.
Date published: 2019-05-11
Rated 1 out of 5 by from Looks good, doesn't work! This unit doesn't rotate. And the screw in one of the legs fell out the first time I used it, I found the screw in the grass but could never find the white plastic seperator piece. Just not a well made product!
Date published: 2019-04-13
Rated 5 out of 5 by from Awesome sprinklers I bought 12 of these over a year ago. They are high output sprinklers and work perfectly. Never a problem. They put out a lot of water therefore require a lot of water to operate. I had to adjust timers so that there were only a couple running at a time or my well pumps couldn't keep up.
Date published: 2019-02-21
Rated 2 out of 5 by from No rotation under 50 psi, but here's how to fix it Several reviewers have remarked about this unit's failure to rotate either out of the box or after some time. The problem is the tension spring that keeps the sprinkler head from rotating freely and just spinning around. The spring that comes with this unit is too strong for water pressures below around 50 psi and needs to be replaced with a shorter or weaker one that only puts slight tension on the head. In the photos below, you can see the location of this spring. To remove this spring and replace it, first disconnect the head from the aluminum tubing of the tripod using Nut "A". Then separate Nut "A" and Nut "B" using two wrenches. Underneath Nut "B", you will see a large straight screwdriver slot. Carefully and lightly clamp the sprinkler head in a vise (or hold it between your legs) so as not to damage it, and turn the screwdriver slot counter-clockwise to disconnect the brass fitting from the green sprinkler head. Now you can remove the spring and replace it with one that has less tension. I had one that was about the same diameter, and cut it so that it only put light tension on the head when it was installed. Sprinkler works great now at lower water pressure. I would rate this product four stars otherwise, but gave it only two because it cost me a lot of my time, and I have trouble with a manufacturer in which NO ONE noticed this problem and changed that spring before shipping it out and causing so much trouble for so many customers.
Date published: 2018-10-08
  • y_2019, m_5, d_19, h_15
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_32
  • loc_en_US, sid_451072299, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_tractorsupply

Why can't I get my to rotate it just stays in one spot?

Asked by: Roxi
Check the metal sprinkler head and see if it was stuck the space, clear them up and it will run to different angles.
Answered by: Valery
Date published: 2018-07-15

I have an older version of this and need to replace the sprinkler head. My calipers show that it is a 1" male thread on the old one. Where can I find a replacement this size?

Asked by: Martyb
The male thread is 3/4”, the caliper show that it is an inner diameter 1” female thread, so please must find a 3/4” outer diameter sprinkler to fit.
Answered by: Valery
Date published: 2017-05-08

How many gallons per minute will this handle? I have well that has a 10 rpm rating and will this work?

Asked by: Bullet69
When under 60psi water pressure, the sprinkler can handle 6 gallons per minute. Please check your email for additional information concerning this product.
Answered by: ErlindaC
Date published: 2018-04-26

what pressure and flow rate do i need to get the 105 radius?

Asked by: Heyblue
The measured reach of 105' is the diameter not the radius. Normal water pressure should provide that coverage.
Answered by: PHailey
Date published: 2019-04-01

Can you remove the stops so it will go around &around

Asked by: George 10
Flip or bend the trip pin upward so it does not hit the trip collar for full circle operation.
Answered by: Valery
Date published: 2018-05-19

How can I order a new tripod, my wife ran over a leg?

Asked by: jeffreyn
Parts are not available for replacement.
Answered by: Valery
Date published: 2017-06-19

Where can I get a,replacement head for my tripod  tsp 4510722 number

Asked by: Dolan
This item will fit a standard impulse sprinkler head with a 3/4" male thread.
Answered by: Astroer
Date published: 2016-08-14
