DIG 25 PSI Pressure Regulator, Inlet 3/4 in. FNPT x Outlet 3/4 in. MNPT
Item # 319120899
Neighbor’s Club Members earn points with purchases.
Out of stock at or near
Grassland (franklin) TN
Out of stock delivering to
37027
This item is not available
Search Stores
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
The DIG 25 PSI Pressure Regulator lowers and regulates the incoming water pressure to an optimal operating pressure for a drip irrigation or micro sprinkler system. These regulators are placed downstream of the valve or filter and are capable of maintaining consistent outlet pressure even when faced with a range of incoming pressures up to 100 PSI. The pressure regulator's design includes few moving plastic parts and a diaphragm which regulates itself in reaction to the overall system back pressure. It offers exceptional pressure control and provides consistent outlet pressures over a wide range of incoming pressures.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Size of the pressure regulator: 3/4 in. FPT (inlet) x 3/4 in. MPT (outlet)
- Easily installed without the need of any tools or adhesives
- Made from durable, high-quality, UV-resistant plastic
- Max incoming pressure of 100 PSI
- Available with 3/4 in. female hose thread or pipe thread to fit all standard hose or pipe thread connections
- Pressure regulator reduces incoming water pressure to the ideal working pressure for a drip system
- High-strength ABS construction for durability
- Compact construction of non-corrosive plastic materials
- Low pressure loss and high flow rate
- Note: DIG's drip irrigation products may be exempt from residential and commercial watering restrictions (check local codes)
- Temperature range: up to 130 degrees F
