Milton Regulator 3/8 in. NPT 2-125 PSI Air Pressure Regulator
Item # 257340099
Neighbor’s Club Members earn points with purchases.
Neighbor’s Club Members earn points with purchases.
Milton's 3/8" NPT Standard Pressure Regulator offers stable downstream air pressure over a wide range of air flows with accurate control, fast response and minimal pressure drop. Regulators should always be preceded by a filter to eliminate damage to the unit or inaccurate air flow. The aluminum die cast body comes with a balanced piston, molded rubber seat, Buna-N diaphragm and O rings. This regulator also has two offset 3/8" gauge ports which can serve as two 3/8" supply lines. As a standard pressure regulator, the 3/8" NPT Mid-Size Standard Regulator has a maximum inlet pressure of 250 PSI with a regulated pressure range of 5-125 PSI.
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Accurate Pressure Control: The Milton 3/8" NPT Standard Pressure Regulator provides accurate control of downstream air pressure, ensuring a stable and consistent output even with varying air flows. This feature is essential for maintaining precision in your compressed air applications.
- Fast Response Time: Benefit from a regulator that responds swiftly to changes in air pressure demands. The fast response time of this regulator enhances the efficiency of your compressed air system, allowing for quick adjustments to meet specific operational requirements.
- Versatile Offset Gauge Ports: The regulator is equipped with offset gauge ports that can double as two 3/8" supply lines. This versatility provides flexibility in the installation process, allowing you to optimize your compressed air setup according to your needs.
- Durable Construction: Crafted with an aluminum die-cast body, balanced piston, and molded rubber seat, this regulator is built to withstand the rigors of industrial environments. The robust construction ensures longevity and reliability in regulating air pressure for your applications.
- Wide Operating Range: With a regulated pressure range of 5-125 PSI and a maximum inlet pressure of 250 PSI, this regulator accommodates a variety of pressure requirements. The operating temperature range of 40 to 120 degrees Fahrenheit adds further versatility, making it suitable for different working conditions.
- Made in USA.
| Brand | Milton |
|---|---|
| Country of Origin | Made in USA |
| Battery Size | None |
| Connection Size | 0.375 in. NPT |
| Connection Type | NPT |
| Display Type | Analog |
| Features | Accurate Pressure Control: The Milton 3/8" NPT Standard Pressure Regulator provides accurate control of downstream air pressure, ensuring a stable and consistent output even with varying air flows. |
| Units Of Measure | PSI |
| Maximum Operating Pressure | 125 PSI |
| Minimum Operating Pressure | 2 PSI |
| Package Quantity | 1 |
| Power Type | Air operated |
| Product Height | 2.75 in. |
| Product Length | 2.63 in. |
| Product Weight | 1.05 lb. |
| Product Width | 7.75 in. |
| Warranty | 1-year |
| Manufacturer Part Number | 1114 |
