JET 5 Ton TS Series Electric Hoist with 10 ft. Lift and 2-Speed Trolley, 460V, 3 Ph
JET 5 Ton TS Series Electric Hoist with 10 ft. Lift and 2-Speed Trolley, 460V, 3 Ph
Item # 1894010
$14597.99
Sale
Was$16219.99
Save $1622.00
JET 5 Ton TS Series Electric Hoist with 10 ft. Lift and 2-Speed Trolley, 460V, 3 Ph
Item # 1894010
$14597.99
Sale
Was$16219.99
Save $1622.00
The JET TS Series 5-Ton Electric Hoist with 10 ft. Lift and 2-Speed Trolley is designed and built for safety, durability and efficient operation in the toughest industrial applications. Designed with two speeds, this durable electric hoist can move materials quickly and safely. The electric hoist allows your material to then slow down to be placed exactly where you need it without the excessive bump firing.
- 2-in-1 design of the mechanical brake and overload protection ensure operator safety and extended product life
- DC motor brake actuates instantly in the event of a power failure to ensure operator safety
- Two speed motor ensures the correct speed for the job with a click of a button
- Electric hoist has an IP55 TEFC motor with Class F insulation for working in harsh environments
- 5-pocket chain sprocket provides reduced vibration, smoother operation and reduced chain wear during long lifting or lowering of loads
- Pendant control is IP65 rated and is fully water-proof, insulated and impact-resistant for years of service
- Built-in heat protection will not allow lifting if internal temperatures exceed 285 degrees F (+/-40 degrees); load will be allowed to be lowered until unit cools; this saves internal components and extends the life of the product
- Electronic hoist comes with a 10 ft. power supply cord
- Available from 1/2 ton to 5 ton capacities
- Safe lifting speeds up to 33 feet per minute and as low as 3 feet per minute to give you the ability to be more efficient with every load
| Brand | JET |
|---|---|
| Country of Origin | Imported |
| Amperage | 8.4/16.8 |
| Chain Length | 10 ft. |
| Features | Insulated Motor |
| Full Load Lifting Speed | 33 FPM |
| Number Of Speeds | 2 |
| Horsepower | 5 HP |
| Lift Assist Ratio | 0 |
| Lift Height | 10 ft. |
| Lift Mechanism | Other |
| Maximum Pull Length | 10 ft. |
| Maximum Weight Capacity | 11,000 lb. |
| Phase | Triple |
| Primary Material | Steel |
| Product Height | 23.622 in. |
| Product Length | 37.008 in. |
| Product Weight | 373.0 lb. |
| Product Width | 27.165 in. |
| Voltage | 460V |
| Warranty | 2 Year |
| Manufacturer Part Number | 140127K |
