GPI Cast Iron Spin-On Fuel Filter Fuel Transfer Pump Adapter
GPI Cast Iron Spin-On Fuel Filter Fuel Transfer Pump Adapter
Item # 395030199
Neighbor’s Club Members earn points with purchases.
Out of stock at or near
Grassland (franklin) TN
Out of stock delivering to
37027
Neighbor’s Club Members earn points with purchases.
The GPI Cast-Iron Spin-On Fuel Filter Fuel Transfer Pump Adapter is for use with spin-on type fuel filters on electric transfer pumps and hand pumps. The fuel filter adapter is designed for mounting to fuel transfer pumps and fuel hose. GPI carries a full line of spare parts, fuel pump adapter fittings and accessories for our fuel pumps and meters. This GPI fuel pump adapter may be purchased individually or as part of the Build-Your-Own program. Order your fuel pump accessories today. Check out more offerings from GPI to get the right equipment for your setup.
Looking for more information on truck accessories? Check out our guide on truck accessories in the product documents section.
- GPI fuel pump adapter dimensions: 3 in. x 4 in. x 2-1/4 in.
- 90 day limited warranty
- Fuel filter adapter is made of cast-iron for strength
- 1 in. NPT outlet allows easy connectivity
- Fuel pump adapter fittings allow you to mount a spin-on type fuel filter on electric transfer and hand pumps
- May be used with gasoline, diesel fuel and kerosene for wide-ranging compatibility
- Must-have fuel pump accessory
| Brand | GPI |
|---|---|
| Country of Origin | Made in USA |
| Body Materials | Cast Iron |
| Compatible Fluids | Gasoline, Kerosene, Diesel |
| Discharge Connection | Threaded Female |
| Discharge Diameter | 1 in. |
| Duty Cycle | N/A |
| Features | GPI 110534-01, bung adapter kit for use with M-150S series fuel transfer pumps, Cast Iron, I in. NPT |
| Hose Diameter | 1 in. |
| Inlet Connection | Threaded Male |
| Inlet Diameter | 1 in. |
| Intended Use Grade | Commercial, Residential, Standard, Industrial |
| Maximum Flow Rate | N/A |
| Maximum Head Lift | N/A |
| Maximum Operating Pressure | 20 gpm |
| Maximum Operating Temperature | 131 degrees F |
| Minimum Operating Pressure | 1 gpm |
| Minimum Operating Temperature | -22 degrees F |
| Power Type | None |
| Product Height | 2-1/4 in. |
| Product Length | 4 in. |
| Product Weight | 2.3 lb. |
| Product Width | 3 in. |
| Warranty | 90 Day Limited |
| Manufacturer Part Number | 110534-01M6TSC |
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Can i use fleet guard ff105 filters on this adapter
2 years ago1 Answer
- A: Hi Tootall, According to the vendor: ‘As long as the filter has 1”- 12 UNF threads it will be compatible.’2 years agoHelpful?
Q: What does a cast iron fuel filter go on?
3 years ago1 Answer
- A: Pump Adapter is for use with spin-on type fuel filters on electric transfer pumps and hand pumps. Fuel pump adapter fittings allow you to mount a spin-on type fuel filter on electric transfer and hand pumps Intended Use Grade Standard, Industrial, Commercial, Residential3 years agoHelpful?
Q: What is the thread pitch of the nipple for the filter?
4 years ago1 Answer
- A: The thread pitch for the filter nipple threads are 1”- 12 UNF threads.4 years agoHelpful?
Q: Can this be used with a CIM TEK 72230 bio tek filter?
5 years ago1 Answer
- A: GPI fuel pump adapter dimensions: 3 in. x 4 in. x 2-1/4 in. Compatibility: Gasoline, diesel fuel and kerosene.5 years agoHelpful?
Q: what filter part number can be used on this adapter?
8 years ago1 Answer
- A: Hello, if you are using the 3/4" adaptor the most common filter is p/n# 129300-01 If you are using a 1" adapter the most common filter is p/n# 129340-06 Please let us know if you have any questions. Thank you, GPI Sales Team.8 years agoHelpful?
Q&As
Have a question?
Start typing your question and we'll check if it was already asked and answered.
1 - 5 of 5 Questions
Newest questions
Q: Can i use fleet guard ff105 filters on this adapter
2 years ago1 Answer
- A: Hi Tootall, According to the vendor: ‘As long as the filter has 1”- 12 UNF threads it will be compatible.’2 years agoHelpful?
Q: What does a cast iron fuel filter go on?
3 years ago1 Answer
- A: Pump Adapter is for use with spin-on type fuel filters on electric transfer pumps and hand pumps. Fuel pump adapter fittings allow you to mount a spin-on type fuel filter on electric transfer and hand pumps Intended Use Grade Standard, Industrial, Commercial, Residential3 years agoHelpful?
Q: What is the thread pitch of the nipple for the filter?
4 years ago1 Answer
- A: The thread pitch for the filter nipple threads are 1”- 12 UNF threads.4 years agoHelpful?
Q: Can this be used with a CIM TEK 72230 bio tek filter?
5 years ago1 Answer
- A: GPI fuel pump adapter dimensions: 3 in. x 4 in. x 2-1/4 in. Compatibility: Gasoline, diesel fuel and kerosene.5 years agoHelpful?
Q: what filter part number can be used on this adapter?
8 years ago1 Answer
- A: Hello, if you are using the 3/4" adaptor the most common filter is p/n# 129300-01 If you are using a 1" adapter the most common filter is p/n# 129340-06 Please let us know if you have any questions. Thank you, GPI Sales Team.8 years agoHelpful?
