EMAX 30 CFM 115V 10A Electric Industrial Refrigerated Air Dryer, 5 Micron Coalescing Filter
Item # 2094999
Neighbor’s Club Members earn points with purchases.
EMAX 30 CFM 115V 10A Electric Industrial Refrigerated Air Dryer, 5 Micron Coalescing Filter
Item # 2094999
This item is available online only
Delivering to
37027
Neighbor’s Club Members earn points with purchases.
Keep Water, Oil, And Dirt Out of Your Compressed Air with EMAX 30CFM 115 voltage Industrial Refrigerated Air Dryer. Purifies compressed air by chilling to condense moisture. Condensate is drained carrying oil & dirt partials away from the air. The bonus auto drain system, eliminates the need for daily maintenance. The EDRCF1150030 prevents corrosion of pipes and tools, resulting in less downtime. With proper filtration, this 30 CFM dryer avoids splotches & stains on your pneumatic air applications. The EMAX 30CFM energy efficient aluminum refrigerated air cooling system is designed for maximum performance and efficiency. Engineered and designed as rust free, stainless steel heat exchanger provides maximum heat transfer, maximum dryer ife and less maintenance. Our EMAX air dryer is the only energy efficient dryer systems with aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger. Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with Non-corrosive inner and after cooler. Our dryers feature stainless steel heat exchanger for maximum dryer life and less maintenance. Emax Air dryers are UL-CSA approved scroll compressor & electric system for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high CFM flow preventing dryer freeze up. 1 year standard warranty-Extended 3 Year warranty with qualifying annual service kit purchase1 year standard warranty-Extended 3 Year warranty with qualifying annual service kit purchase
For additional information on this product, please see the Product Documents section for all downloadable user manuals, installation guides, brochures and warranty statements.
- Great for a 5 Horsepower to 7.5 Horsepower air compressor systems
- Environmentally friendly 134A refrigerant
- 30 CFM 60hz 115 Voltage
- Easy To Install- Uses 120V single-phase power, no special wiring needed
- Added features: Auto Drain System, Refrigerant Pressure Gauge, Outlet Air Baffle Heater
- Refrigerant pressure gauge clearly monitors performance of dew point temp (models under 400 CFM)
- Outlet air baffle heater prevents condensation on outlet air piping
- Heavy duty steel cabinet
- Trouble free operation refrigerated air inlet inner cooler for high temp cooling
- Top mounted condenser & fan motor
- MADE IN GERMANY
- Dimensions: 16" x 18" x 24", 110 lbs
- Trouble free operation refrigerated air inlet inner cooler for high temp cooling
- Filtration: Built in 1 Micron Active Coalescing
- Dew Point: 37-59 degrees Fahrenheit
- Maximum ambient temperature: 122 degrees Fahrenheit
- Pre-Filtration: 5 Micron
- Maximum working PSI: 230
- Side mounted condenser & Fan Motor
- Outlet air baffle heater - prevents condensation on outlet air piping
- Inlet & Outlet Pipe size: 1/2 inch
- Certifications: ETL, UL & ASME
