Barn Star Digital Multimeter with Test Leader
Online Only
Barn Star Digital Multimeter with Test Leader
Item # 1858759
$14.99
Neighbor’s Club Members earn points with purchases.
$14.99
This item is available online only
Out of stock delivering to
37027
This item is not available
Search Stores
Temporarily unavailable
Neighbor’s Club Members earn points with purchases.
Measure quantities, such as voltage, current and resistance, safely and easily with the Barn Star Digital Multimeter with Test Leader. This user-friendly digital multimeter with a test leader features a PVC shockproof holster for security. Made of reliable materials, this digital multimeter is ready to handle a variety of job tasks and DIY projects.
- Large screen on the digital multimeter for easy reading
- PVC shockproof holster for added protection
- Data hold function for reading after measurement
| Brand | Barn Star |
|---|---|
| Country of Origin | Imported |
| Accuracy | 4 Pct. |
| Battery Size | AA |
| Display Type | LCD |
| Features | DCV,ACV,DCA,ACA,Resistance,Capacitance |
| Housing Material | ABS |
| Maximum AC Voltage Measurement | 600V |
| Maximum DC Amperage Measurement | 10A |
| Maximum DC Voltage Measurement | 600V |
| Maximum Frequency | 0 Hz |
| Maximum Resistance | 200MOmega |
| Minimum AC Amperage Measurement | 2 m |
| Minimum AC Voltage Measurement | 200 m |
| Minimum DC Amperage Measurement | 2 m |
| Minimum DC Voltage Measurement | 200 m |
| Minimum Frequency | 0 Hz |
| Power Type | Battery |
| Product Height | 9.2 cm |
| Product Length | 18.9 cm |
| Product Weight | 322 g |
| Product Width | 3.4 cm |
| Warranty | N/A |
| Manufacturer Part Number | DT9205A |
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: How do you check for capacitance?
5 months ago1 Answer
- A: Please follow below steps to test capacitance. Below photo is also for your reference. 1) Connect the BLACK test lead to the COM jack, and the RED to the mA jack. 2) Set the function switch at F position. (NOTE: The polarity of the RED lead is positive “+”) 3) Connect test leads across the capacitor under measure and be sure the polarity of connection is observed. 4) The meter standard multi-function socket also can be used as measuring capacitor socket. Note: To avoid damage to the meter, disconnect circuit power and discharge all high-voltage capacitors before measuring capacitance. The tested capacitor should be discharged before the testing procedure. Never apply voltage to the input, or serious damage may result.5 months agoHelpful?
Q: Trying to test deer feeder battery's. Some are 6 Volt and some are 12. Specifications shows AA battery. Will this check 6v and 12v. battery's?
6 months ago1 Answer
- A: Yes, the Barn Star Digital Multimeter DT9205A can measure both 6V and 12V batteries because it has a DC voltage range that includes these values6 months agoHelpful?
Q: Can it check Electric fence?
6 months ago1 Answer
- A: No, the Barn Star Digital Multimeter DT9205A cannot safely or accurately check an electric fence because its maximum voltage rating is far lower than the voltage output of an electric fence. Using a regular multimeter on an energized electric fence can destroy the meter and poses a safety risk6 months agoHelpful?
Q: Does the meter have over current protection( a replaceable fuse)?
9 months ago1 Answer
- A: Yes, the multimeter has over current protection (mA: F0.5A/600V fuse; 10A: F10A/600V fuse).8 months agoHelpful?
Q: How do you connect the connectors to the machine to test a battery and alternator? Which whole is for what
a year ago1 Answer
- A: 1. Connect the black test lead to the "COM" jack and the red test lead to "VΩ" jack. 2. Turn the button to 20V, and then use the red test lead to touch battery"+", and the black test lead to touch battery"-". 3. Generally the voltage is no less than 1.5V for a new battery.a year agoHelpful?
Q: What type of battery (s) does this multimeter use and is it included?
a year ago1 Answer
- A: This Multimeter uses a 9V battery, and it is included in the product.a year agoHelpful?
Q: My meter doesn't have any screws in it . How does it come open to put battery in
a year ago1 Answer
- A: First, remove the protective case, then release the 3 screws Open the multimeter you will see the position of the battery.a year agoHelpful?
Q: Can this be used for a car?
a year ago1 Answer
- A: Yes, this can be used for a car.a year agoHelpful?
Q: How to install battery
a year ago1 Answer
- A: First, remove the protective case, then release the 3 screws Open the multimeter you will see the position of the batta year agoHelpful?
Q: Does this meter have an automatic off?
a year ago1 Answer
- A: Yes, it has an automatic off.a year agoHelpful?
1 - 10 of 15 Questions
Q&As
Start typing your question and we'll check if it was already asked and answered.
1 - 10 of 15 Questions
Newest questions
Q: How do you check for capacitance?
5 months ago1 Answer
- A: Please follow below steps to test capacitance. Below photo is also for your reference. 1) Connect the BLACK test lead to the COM jack, and the RED to the mA jack. 2) Set the function switch at F position. (NOTE: The polarity of the RED lead is positive “+”) 3) Connect test leads across the capacitor under measure and be sure the polarity of connection is observed. 4) The meter standard multi-function socket also can be used as measuring capacitor socket. Note: To avoid damage to the meter, disconnect circuit power and discharge all high-voltage capacitors before measuring capacitance. The tested capacitor should be discharged before the testing procedure. Never apply voltage to the input, or serious damage may result.5 months agoHelpful?
Q: Trying to test deer feeder battery's. Some are 6 Volt and some are 12. Specifications shows AA battery. Will this check 6v and 12v. battery's?
6 months ago1 Answer
- A: Yes, the Barn Star Digital Multimeter DT9205A can measure both 6V and 12V batteries because it has a DC voltage range that includes these values6 months agoHelpful?
Q: Can it check Electric fence?
6 months ago1 Answer
- A: No, the Barn Star Digital Multimeter DT9205A cannot safely or accurately check an electric fence because its maximum voltage rating is far lower than the voltage output of an electric fence. Using a regular multimeter on an energized electric fence can destroy the meter and poses a safety risk6 months agoHelpful?
Q: Does the meter have over current protection( a replaceable fuse)?
9 months ago1 Answer
- A: Yes, the multimeter has over current protection (mA: F0.5A/600V fuse; 10A: F10A/600V fuse).8 months agoHelpful?
Q: How do you connect the connectors to the machine to test a battery and alternator? Which whole is for what
a year ago1 Answer
- A: 1. Connect the black test lead to the "COM" jack and the red test lead to "VΩ" jack. 2. Turn the button to 20V, and then use the red test lead to touch battery"+", and the black test lead to touch battery"-". 3. Generally the voltage is no less than 1.5V for a new battery.a year agoHelpful?
Q: What type of battery (s) does this multimeter use and is it included?
a year ago1 Answer
- A: This Multimeter uses a 9V battery, and it is included in the product.a year agoHelpful?
Q: My meter doesn't have any screws in it . How does it come open to put battery in
a year ago1 Answer
- A: First, remove the protective case, then release the 3 screws Open the multimeter you will see the position of the battery.a year agoHelpful?
Q: Can this be used for a car?
a year ago1 Answer
- A: Yes, this can be used for a car.a year agoHelpful?
Q: How to install battery
a year ago1 Answer
- A: First, remove the protective case, then release the 3 screws Open the multimeter you will see the position of the batta year agoHelpful?
Q: Does this meter have an automatic off?
a year ago1 Answer
- A: Yes, it has an automatic off.a year agoHelpful?
1 - 10 of 15 Questions
Similar Items
-
-
-
-
-
-
-
-
-
Top Rated
-
Top Rated
-
Top Rated
-
Items You May Like
-
-
-
-
-
-
-
Top Rated
-
-
-
-
-
Customers Also Bought
-
-
-
-
-
-
-
-
-
Top Rated
-
Top Rated
-
-
Top Rated
Reviews
- price
- purchase
- quality
- returns
- satisfaction
1 to 4 of 9 Reviews .
1 – 4 of 9 Reviews
Most Recent
Review 1
1 out of 5 stars.
Lower quality discount meter
5 months ago
I got this meter on sale and tried it out. The screen was incomplete and unable to be use. I took it back and got a replacement. That meter had the same issues. It’s a lower quality piece of equipment.
Review 1
5 out of 5 stars.
Multimeter
2 years ago
It has a stand allowing table top use. It’s durable, easy to read, & easy to use. The meter has a protective cover. The test probes are of good quality. It’s multifunctional & a decent size. Good quality for a good price.
SweepstakesYes
Yes, I recommend this product.
Florida
Reviews 2
2 out of 5 stars.
An OK Multimeter
2 years ago
It works OK, but there are a lot better Multimeters for less money. Very small and easy to store.
Yes, I recommend this product.
Reviews 2
5 out of 5 stars.
Works great.
2 years ago
It seems to work fine. Its a very basic Multimeter with the functions one would expect. For the cost its easily worth the purchase if your needing something to do some simple circuit or voltage testing.
2023 Q4 SweepstakesNo
