Magister Hydraulics 5 in. Bore x 30 in. Stroke Log Splitter Hydraulic Cylinder
Magister Hydraulics 5 in. Bore x 30 in. Stroke Log Splitter Hydraulic Cylinder
Item # 601604299
$525.99
or
or
Neighbor’s Club Members earn points with purchases.
Magister Hydraulics 5 in. Bore x 30 in. Stroke Log Splitter Hydraulic Cylinder
Item # 601604299
$525.99
or
or
$44/mo.† suggested payments with 12 Months Financing or earn $26 in Rewards+ on this purchase.
This item is available online only
Delivery to
Free standard delivery on online footwear & Clothing purchases of $49 and over.
Neighbor’s Club Members earn points with purchases.
Built for strength and performance, the Magister Hydraulics Welded Log Splitter Cylinder features a 5-inch bore, 30-inch stroke, and is rated up to 3500 PSI. It comes equipped with a welded clevis base mount and a drilled pin-hole rod end for secure, stable installation. This universal replacement ram is compatible with a wide range of log splitter brands, including Champion, YARDMAX, CountyLine, Huskee, SuperHandy, BOSS, and others.
Looking for more information on hydraulics? Check out our guide on hydraulics in the product documents section.
- Extreme Load Capacity: Welded clevis mount base end, 5.5" honed cold-drawn tubing, 2.0" chrome-plated rod (steel 1045) with drilled pin-hole rod end for easy mounting and top-quality piston seals make it capable of handling heavy loads with a 30" stroke.
- High-Quality Construction: Steel piston and steel gland with wear rings, crafted from premium-grade materials, offering exceptional durability, corrosion resistance, and long-lasting service life.
- Precision Engineering: Designed with tight tolerances and advanced sealing technology to minimize leakage and maintain optimal performance.
- 2-year warranty
- Same Day Shipping
- Made in Europe
| Brand | Magister Hydraulics |
|---|---|
| Country of Origin | Imported |
| Bore Diameter | 5 in. |
| Brand Compatibility | Universal |
| Compatibility | Universal |
| Extended Length | 70.5 in. |
| Hydraulic Cylinder Type | Welded Double Acting |
| Maximum Operating Pressure | 3500 PSI |
| Maximum Weight Capacity | 58900 lb. |
| Model Compatibility | Universal |
| Package Quantity | 1 |
| Pin Diameter | 0.563 in. |
| Port Size | 1/2" NPT |
| Primary Material | Steel |
| Product Height | 7 in. |
| Product Length | 47 in. |
| Product Weight | 103 lb. |
| Product Width | 7 in. |
| Retracted Length | 40.5 in. |
| Rod Diameter | 2 in. |
| Single/Double Acting | Double acting |
| Stroke Distance | 30 in. |
| Warranty | 2 Years |
| Manufacturer Part Number | WLS 5x30 |
